Wurth Elektronik WR-PHD Series Straight Through Hole PCB Socket 8-Contact 1 Row 2 mm Pitch Solder 62000811821
Specifications
| Country of Origin | China |
|---|---|
| Voltage | 200V |
| Brand | Wurth Elektronik |
| Orientation | Straight |
| Current | 2A |
| Mount Type | Through Hole |
| Housing Material | Polyamide 9T |
| Contact Material | Copper Alloy |
| Series | WR-PHD |
| Durability | 500 mating cycles |
| Termination Type | Solder |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -40°C |
| Number of Rows | 1 |
| Pitch | 2mm |
| Standards/Approvals | DIN EN 61760-2, RoHS Approval, UL Approval E323964, REACh Approval Conform or declared, DIN ISO 2768 |
| Contact Plating | Gold |
| Number of Contacts | 8 |
| Contact Gender | Female |
Key Features
- Constructed with polyamide 9T housing material ensuring high durability.
- Features copper alloy female contacts with gold plating for optimum conductivity.
- Designed for through hole mounting providing strong mechanical stability.
- Operates safely at voltages up to 200V and current rating of 2A.
- Suitable for industrial PCB applications with operating temperature range from -40°C to 105°C.
- Meets multiple standards including DIN EN 61760-2, RoHS, UL Approval E323964, and REACh compliance.
- Durability tested to 500 mating cycles ensuring long-term reliable performance.
Product Description
Wurth Elektronik 62000811821 WR-PHD Series Straight Through Hole PCB Socket is engineered for high-quality electronic PCB assembly requiring stable and durable connections. Featuring 8 female contacts in a single-row configuration with 2 mm pitch solder termination, it is ideal for compact circuit designs where precise contact spacing is critical.
The socket is fabricated with polyamide 9T housing material offering excellent mechanical strength and flame resistance compliant with UL94 V-0 standards. Copper alloy contact material with gold plating assures superior electrical conductivity while resisting corrosion in industrial environments.
This PCB socket supports a continuous voltage rating of 200V with a current capacity of 2 amps, making it suitable for a range of electronic power and signal applications. It is designed for through-hole mounting, providing secure solder joints and mechanical robustness during assembly and operation.
Its wide operating temperature range from -40°C to 105°C affords versatility in various industrial and environmental conditions. The socket complies with key industry standards including DIN EN 61760-2, RoHS, UL E323964, and REACh, supporting regulatory requirements for high-reliability electronics manufacturing.
Housing material: Polyamide 9T with UL94 V-0 flammability rating. Contact gender: Female with copper alloy and gold plating for durability and conductivity. Mounting type: Through hole ensuring strong mechanical fixation.
Electrical ratings: 200V voltage and 2A current for power and signal transfer. Operating temperature range: -40°C to +105°C suitable for harsh environments. Durability: Rated for 500 mating cycles to guarantee long service life.
Standards: DIN EN 61760-2, RoHS compliant, UL Approval E323964, and REACh approved.
This PCB socket is well suited for use in industrial electronics, manufacturing equipment, power distribution systems, and other applications requiring reliable electrical interconnections on printed circuit boards. It provides a quality solution for engineers focusing on durable and efficient PCB connector designs.
Explore the Wurth Elektronik product range and other PCB Socket solutions available at EnvMart for all your electronic component and assembly needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This PCB socket operates safely at a voltage of 200V and has a current rating of 2A.
It has an operating temperature range from -40°C to 105°C, making it suitable for various industrial conditions.
The housing is made from polyamide 9T, while the contacts are copper alloy with gold plating for improved conductivity.
This model features 8 female contacts arranged in a single-row configuration.
The pitch size of this socket is 2 mm, which is critical for compact circuit designs.
It is rated for 500 mating cycles, ensuring long-term reliable performance during use.
This socket is designed for through-hole mounting, providing strong mechanical stability during assembly.
It meets several standards including DIN EN 61760-2, RoHS, UL Approval E323964, and REACh compliance.
The orientation of this model is straight, designed for straightforward installation on PCBs.
This PCB socket features solder termination, which is standard for secure connections on printed circuit boards.
It is suitable for industrial electronics, manufacturing equipment, and power distribution systems requiring reliable electrical interconnections.
The country of origin for this socket is China.
