Power Integrations Flyback Converter IC, Off Liner, 6.1W, 700V, 7-Pin DIP, Through Hole LNK606PG
Specifications
| Country of Origin | India |
|---|---|
| Brand | Power Integrations |
| Height | 3.68mm |
| Length | 9.83mm |
| Model | LNK606PG |
| Width | 6.6mm |
| Mount Type | Through Hole |
| Number of inputs | 1 |
| Series | LinkSwitch-II |
| Power Rating | 6.1W |
| Maximum Operating Temperature | 150°C |
| Package Type | DIP |
| Minimum Operating Temperature | -40°C |
| Operating Current | 600μA |
| Number of outputs | 5 |
| Standards/Approvals | RoHS, EN55022 Class B |
| Pin Count | 7 |
| Maximum Supply Voltage | 700V |
Key Features
- Supports flyback power conversion for efficient energy regulation.
- Provides 6.1W power rating with up to 700V maximum supply voltage.
- 7-pin DIP package ensures secure mounting and straightforward integration in PCB designs.
- Operates from -40°C to 150°C, reliably handling wide temperature ranges.
- Complies with RoHS and EN55022 Class B standards for quality and safety.
- Features a single input and five outputs, suitable for multi-rail designs.
- Low operating current of 600μA optimizes energy consumption.
- Through hole mounting allows robust installation in industrial and commercial applications.
Product Description
Power Integrations LNK606PG Flyback Converter IC is a high-efficiency off liner power switch suited for low-power CV/CC charger designs and industrial power management applications. The device utilizes a flyback converter topology to efficiently regulate voltage and current output, compensating for transformer and internal parameter variations and input voltage changes. Its innovative control technique eliminates the need for optocoupler and secondary control circuitry, streamlining system designs and improving reliability.
This IC provides a 6.1W power rating with a maximum supply voltage of 700V and features a 7-pin DIP package for convenient through hole installation. With an operating current of only 600μA, the LNK606PG supports designs demanding low power consumption. The device is designed to operate under extreme temperature conditions, from -40°C to 150°C, making it versatile for a wide range of environments.
Its five outputs can deliver precise voltage and current regulation, allowing easy compliance with global energy efficiency regulations and simplifying multi-output power rail applications. The IC also complies with RoHS and EN55022 Class B standards, ensuring safety and environmental compatibility.
The LNK606PG is part of the LinkSwitch-II series from Power Integrations, offering advanced features for modern power management. The 7-pin DIP form factor facilitates secure and straightforward PCB assembly, while through hole mounting provides robust mechanical stability - ideal for industrial, laboratory, and commercial solutions.
This converter IC is frequently used in charger modules, power adapters, LED drivers, consumer electronics, and instrumentation for precise supply switching and power conversion tasks. Its combination of compact design, broad operating temperature range, and efficient performance makes it a preferred component in electronics manufacturing and development.
Supports flyback converter applications in industrial, laboratory, and commercial equipment. Integrated energy-saving features suitable for global regulatory compliance environments. Suitable for power supplies in instrumentation, chargers, adapters, consumer devices, and industrial control panels.
7-pin DIP package enables simple integration into existing PCB layouts and systems. Reliable through hole mounting for enduring installation and maintenance. For more options in Power Switch ICs and advanced converter components, browse the Power Integrations category on EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The LNK606PG has a power rating of 6.1W.
This model can handle a maximum supply voltage of 700V.
It operates within a temperature range from -40°C to 150°C.
The LNK606PG features five outputs.
This model utilizes a through hole mounting type for secure installation.
The dimensions of this IC are 9.83mm in length, 6.6mm in width, and 3.68mm in height.
It complies with RoHS and EN55022 Class B standards.
The operating current for the LNK606PG is 600μA.
This model is part of the LinkSwitch-II series from Power Integrations.
It is suitable for applications such as charger modules, power adapters, LED drivers, and instrumentation.
This flyback converter IC has one input.
The 7-pin DIP package allows for straightforward integration into PCB designs and ensures secure mounting.
