Crydom 1 Series Solid State Relay 10A, Panel Mount, 280Vrms Load, 90 - 280V Control, SCR Output, A2410
Specifications
| Country of Origin | India |
|---|---|
| Brand | Crydom |
| Height | 23mm |
| Length | 58.4mm |
| Model | A2410 |
| Width | 22.6mm |
| Mount Type | Panel |
| Output type | SCR |
| Series | 1 |
| Maximum Operating Temperature | 80°C |
| Dielectric strength | 4000 Vrms |
| Capacitance | 8pF |
| Minimum Operating Temperature | -40°C |
| Terminal type | Screw |
| Switching Function | Zero Voltage Switching |
| Maximum Load Current | 10A |
| Standards/Approvals | RoHS |
| Minimum Load Voltage | 24V ac/dc |
| Minimum Control Voltage | 90V ac/dc |
| Off State Leakage Current | 1mA |
| 10A AC CONT SSRBrand | NEUTRAL |
Key Features
- Switches loads up to 10A at voltages to 280Vrms.
- Supports a wide control voltage range of 90V to 280V AC/DC.
- Utilizes SCR output for efficient, reliable switching of high-power loads.
- Features zero voltage switching for precise control and reduced electrical noise.
- Constructed in a compact panel-mount housing with screw terminals for easy installation.
- Handles harsh conditions with operating temperature range from -40°C to +80°C.
- Dielectric strength rated at 4000Vrms for enhanced safety and insulation.
- Integrates anti-rotation barriers for vibration resistance in demanding industrial environments.
Product Description
The Crydom A2410 is a member of the 1 Series solid state relays, designed for precise and reliable switching of AC loads in industrial and automation settings. Built with an SCR output stage and engineered to carry up to 10A at 280Vrms, this SSR enables rapid response with half-cycle turn-on/off times, ensuring efficient performance for high-frequency switching operations without mechanical wear or contact degradation.
This relay supports control voltages from 90V to 280V AC/DC and can handle load voltages up to 280Vrms, making it suitable for a range of automation tasks, electrical regulation, or motor starting applications. The A2410 offers zero voltage switching, which minimizes electrical noise and output transients, making it ideal for environments where equipment reliability and reduced electromagnetic interference are critical.
Durability is a core feature, with an operating temperature range spanning -40°C to +80°C, and a robust flame-retardant housing. The relay's dielectric strength of 4000Vrms enhances safety and isolation for connected systems. With a wide range of industrial approvals and RoHS compliance, it is suitable for use in regulated environments.
The A2410 is designed for easy integration with panel mounting and pre-assembled SEMS screw and washer sets, facilitating quick installation. Anti-rotation barriers provide added stability during use, especially in locations with high vibration such as industrial machinery or process equipment. Its compact size - 58.4mm length, 23mm height, and 22.6mm width - allows for space-saving control panel layouts.
Common applications include industrial automation panels, motor control, heating/cooling systems, lamp or solenoid driving, and more. Its long mean time between failures (MTBF over 1300 years at +40°C) ensures reliability in continuous-duty environments where maintenance downtime is costly. Explore more automation solutions and Solid State Relays from Crydom and related categories on EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum load current for this model is 10A.
It supports a control voltage range from 90V to 280V AC/DC.
The dielectric strength is rated at 4000Vrms, providing enhanced safety and insulation.
It has dimensions of 58.4mm in length, 23mm in height, and 22.6mm in width.
The operating temperature range is from -40°C to +80°C.
This model utilizes an SCR output for efficient and reliable switching of high-power loads.
Zero voltage switching minimizes electrical noise and output transients, enhancing equipment reliability.
It is designed for panel mounting and includes screw terminals for easy installation.
The minimum load voltage is 24V AC/DC.
Common applications include industrial automation panels, motor control, heating/cooling systems, and lamp or solenoid driving.
The relay is RoHS compliant, indicating it meets certain environmental standards.
It features screw terminals, facilitating secure electrical connections.
