Nexperia Bi-Directional ESD Protection Diode PESD15VL1BA,115, 200 W, 2-Pin UMD, Surface Mount, 17.1 V Breakdown Voltage
Specifications
| Country of Origin | China |
|---|---|
| Brand | Nexperia |
| Height | 1.05mm |
| Length | 1.8mm |
| Model | PESD15VL1BA,115 |
| Width | 1.35mm |
| Mount Type | Surface |
| Series | PESD |
| Maximum Operating Temperature | 150°C |
| Package Type | UMD |
| Minimum Operating Temperature | -65°C |
| Pin Count | 2 |
| Number of Elements per Chip | 1 |
| Clamping Voltage VC | 44V |
| Automotive Standard | AEC-Q101 |
| Diode Configuration | Single |
| Direction Type | Bi-Directional |
| Minimum Breakdown Voltage Vbr | 17.1V |
| Maximum Reverse Stand-off Voltage Vwm | 15V |
| Peak Pulse Power Dissipation Pppm | 200W |
| Test Current It | 5mA |
| Maximum Peak Pulse Current Ippm | 5A |
| Maximum Reverse Leakage Current | 50nA |
Key Features
- Bi-directional ESD protection diode for advanced circuit safety.
- Peak Pulse Power Dissipation rated at 200 W for high protection capacity.
- Surface mount UMD package streamlines integration into compact devices.
- Minimum breakdown voltage of 17.1 V ensures reliable transient suppression.
- Maximum reverse stand-off voltage of 15 V suitable for modern electronics.
- Low leakage current of 50 nA maximizes efficiency and minimizes loss.
- Automotive-compliant to AEC-Q101 standards for demanding environments.
Product Description
Nexperia PESD15VL1BA,115 is a bi-directional ESD protection diode designed for safeguarding sensitive electronic components from transient voltage surges and electrostatic discharge events. With a peak pulse power dissipation of 200 W and a compact surface-mount UMD package, it delivers robust protection while optimizing PCB space utilization. Its single-diode configuration accommodates advanced electronics and supports reliable circuit safety.
The device features a minimum breakdown voltage of 17.1 V, a maximum reverse stand-off voltage of 15 V, and a clamping voltage of 44 V. These characteristics make it ideal for integration into signal lines requiring stringent ESD protection, especially in high-reliability automotive and industrial applications. The low reverse leakage current (50 nA) complements efficient circuit operation.
Automotive systems benefit from its compliance with AEC-Q101 standards, ensuring operational reliability from -65°C to +150°C. The UMD package with 2-pin design enables easy surface-mount installation and supports modern assembly methods.
Applications for this ESD protection diode include electronics, industrial automation, automotive control units, and consumer electronic devices where high transient immunity is critical. It is used in protecting microcontrollers, communication lines, and sensor interfaces from damage caused by voltage spikes and static discharge.
The PESD15VL1BA,115 belongs to Nexperia’s low capacitance PESD series, providing efficient bidirectional protection in small form factors. Its technical attributes facilitate seamless integration and facilitate circuit longevity.
Explore more TVS Diodes under the Electronics & Electricals category, and browse Nexperia’s advanced semiconductor solutions at EnvMart.
