Vishay 1-Element Uni-Directional TVS Diode 600 W, 2-Pin DO-214 SM6T36A-E3/52
Specifications
| Country of Origin | India |
|---|---|
| Brand | Vishay |
| Height | 2.24mm |
| Length | 4.57mm |
| Model | SM6T36A-E3/52 |
| Width | 3.94mm |
| Mount Type | Surface |
| Series | TRANSZORB TVS |
| Maximum Operating Temperature | 150°C |
| Package Type | DO-214 |
| Minimum Operating Temperature | -65°C |
| Pay online using | Or choose to pay later via bank transfer |
| RS Stock No. | 710-4979Brand: VishayManufacturers Part No.: SM6T36A-E3/52 |
| Pin Count | 2 |
| Number of Elements per Chip | 1 |
| Clamping Voltage VC | 64.3V |
| Automotive Standard | AEC-Q101 |
| Diode Configuration | Single |
| Direction Type | Uni-Directional |
| Minimum Breakdown Voltage Vbr | 34.2V |
| Maximum Reverse Stand-off Voltage Vwm | 30.8V |
| Peak Pulse Power Dissipation Pppm | 600W |
| Test Current It | 1mA |
| Maximum Peak Pulse Current Ippm | 62A |
| Maximum Reverse Leakage Current | 1μA |
Key Features
- Single diode configuration suitable for protection against voltage spikes.
- Uni-directional design with a 2-pin DO-214 package.
- Minimum breakdown voltage of 34.2 V for stable operation.
- Capable of withstanding peak pulse currents up to 62 A.
- Surface mount type ideal for compact electronic assemblies.
- Clamping voltage of 64.3 V to protect sensitive circuits.
- Wide operating temperature range from -65°C to 150°C for reliability in harsh conditions.
- Complies with automotive standard AEC-Q101 for quality assurance.
Product Description
Vishay SM6T36A-E3/52 is a single-element uni-directional transient voltage suppressor (TVS) diode designed for effective protection of sensitive electronic components from voltage transients and surges. The device offers a peak pulse power dissipation rating of 600 W and is packaged in a compact 2-pin DO-214 surface mount configuration.
Featuring a minimum breakdown voltage of 34.2 V, it ensures reliable clamping at a voltage of 64.3 V to protect circuits from electrostatic discharge and voltage spikes. Its ability to handle a maximum peak pulse current of 62 A makes it suitable for industrial, automotive, and consumer electronics applications requiring robust overvoltage protection.
Operating reliably over a broad temperature range from -65°C to 150°C, the SM6T36A-E3/52 complies with automotive standard AEC-Q101, certifying its suitability for automotive electronic systems. The device's low leakage current (1 μA maximum) and surface mount package provide convenience for PCB assembly in compact designs.
This TVS diode is part of Vishay's TRANSZORB TVS series, widely used in transient voltage suppressors for industrial, automotive, and consumer electronics to enhance device longevity and safeguard sensitive components from transient events.
Single diode configuration suitable for protection against voltage spikes. Uni-directional design with a 2-pin DO-214 package. Minimum breakdown voltage of 34.2 V for stable operation. Capable of withstanding peak pulse currents up to 62 A.
Surface mount type ideal for compact electronic assemblies. Clamping voltage of 64.3 V to protect sensitive circuits. Wide operating temperature range from -65°C to 150°C for reliability in harsh conditions. Complies with automotive standard AEC-Q101 for quality assurance.
This product is ideal for use in electronics manufacturing, automotive electronics, power supply design, and other applications requiring transient voltage suppression. Explore our full range of TVS Diodes and electronics components on EnvMart for comprehensive protection solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The Vishay SM6T36A-E3/52 has a peak pulse power dissipation rating of 600 W.
The minimum breakdown voltage for the SM6T36A-E3/52 is 34.2 V, ensuring stable operation.
The clamping voltage of this model is 64.3 V, which protects sensitive circuits from voltage spikes.
This TVS diode can withstand a maximum peak pulse current of 62 A.
The SM6T36A-E3/52 operates reliably over a temperature range from -65°C to 150°C.
It is packaged in a compact 2-pin DO-214 surface mount configuration.
This model complies with the automotive standard AEC-Q101, certifying its suitability for automotive applications.
The maximum reverse leakage current for the SM6T36A-E3/52 is 1 μA.
This model features a single-element configuration, designed for effective voltage suppression.
The dimensions of the SM6T36A-E3/52 are 2.24 mm in height, 4.57 mm in length, and 3.94 mm in width.
The SM6T36A-E3/52 is a uni-directional TVS diode, suitable for protecting against voltage spikes.
This TVS diode is suitable for use in electronics manufacturing, automotive electronics, and power supply design, among others.
