Nexperia Uni-Directional ESD Protection Diode Surface Mount DFN2510D Package PESD4USB3U-TTS
Specifications
| Country of Origin | India |
|---|---|
| Brand | Nexperia |
| Height | 1mm |
| Length | 2.5mm |
| Model | PESD4USB3U-TTS |
| Width | 0.75mm |
| Mount Type | Surface |
| Series | PESD4USB3U-TTS |
| Maximum Operating Temperature | 150°C |
| Package Type | DFN2510D |
| Minimum Operating Temperature | -65°C |
| Interfaces | USB 2 |
| Standards/Approvals | IEC 61000-4-2 |
| Clamping Voltage VC | 3.5V |
| Automotive Standard | AEC-Q101 |
| Direction Type | Uni-Directional |
| Minimum Breakdown Voltage Vbr | 6V |
| Maximum Reverse Stand-off Voltage Vwm | 3.3V |
| Maximum Peak Pulse Current Ippm | 7A |
| Maximum Reverse Leakage Current | 100nA |
| Infotainment applications | USB 2.0, SuperSpeed USB 3.2 at 10 Gbps, HDMI 2.0, HDBaseT |
Key Features
- Offers uni-directional ESD protection with a minimum breakdown voltage of 6 V.
- Maximum reverse stand-off voltage is 3.3 V ensuring effective surge suppression.
- Capable of handling peak pulse currents up to 7 A with clamping voltage of 3.5 V.
- Operates reliably in temperature ranges from -65°C to 150°C.
- Compact dimensions of 2.5 mm length, 0.75 mm width, and 1 mm height for easy PCB integration.
- Compliant with IEC 61000-4-2 and automotive standard AEC-Q101.
- Specifically designed to protect USB 2.0, SuperSpeed USB 3.2 at 10 Gbps, HDMI 2.0, and HDBaseT interfaces.
- Features low line capacitance of 0.5 pF per channel supporting signal integrity.
Product Description
Nexperia PESD4USB3U-TTS is a uni-directional ESD protection diode housed in a compact DFN2510D surface-mount package. It is engineered to safeguard high-speed data interfaces against electrostatic discharge, ensuring signal integrity and device reliability in demanding industrial, automotive, and consumer electronics environments.
This ESD diode offers a minimum breakdown voltage of 6 V and a maximum reverse stand-off voltage of 3.3 V. It can handle peak pulse current spikes up to 7 A with a low clamping voltage of 3.5 V, providing effective protection during transient surge events.
Designed with a minimal line capacitance of 0.5 pF per channel, it supports high-speed data transfer over interfaces like SuperSpeed USB 3.2 (10 Gbps), HDMI 2.0, and HDBaseT without degrading signal quality. The device meets strict automotive AEC-Q101 standards and IEC 61000-4-2 compliance for robust system-level ESD protection.
Its small footprint (2.5 mm length, 0.75 mm width, 1 mm height) and side-wettable flank leads enable reliable soldering and compatibility with automatic assembly lines. Applications include automotive infotainment systems, display units, cameras, serial advanced technology attachment (eSATA), low voltage differential signaling (LVDS), and gigabit multimedia serial links (GMSL) Serializer/Deserializer (SerDes) circuits.
Uni-directional ESD protection device designed for high-speed interfaces. Compact DFN2510D package suitable for surface mount technology. Min breakdown voltage 6 V, max reverse stand-off voltage 3.3 V. Peak pulse current capacity of 7 A with low clamping voltage (3.5 V).
Operating temperature range: -65°C to 150°C. IEC 61000-4-2 and AEC-Q101 compliant for automotive use. Low line capacitance ensures minimal signal degradation. Matched 0.5 mm trace spacing and side-wettable flanks for assembly reliability.
Ideal for USB 2.0, SuperSpeed USB 3.2, HDMI 2.0, HDBaseT, automotive displays and cameras.
This Nexperia PESD4USB3U-TTS diode is essential for protecting sensitive electronics from ESD-induced damage in complex, high-speed digital and automotive environments. Explore the Electronics & Electricals category at EnvMart for related semiconductor protection components and other Nexperia products.
Explore more products in our TVS Diodes category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The minimum breakdown voltage of this diode is 6 V.
It can handle peak pulse currents up to 7 A.
The clamping voltage is 3.5 V.
This model operates reliably in temperature ranges from -65°C to 150°C.
The dimensions are 2.5 mm in length, 0.75 mm in width, and 1 mm in height.
The line capacitance is 0.5 pF per channel, which supports signal integrity.
It complies with the automotive standard AEC-Q101.
Yes, it is compliant with IEC 61000-4-2 for ESD protection.
This diode uses a surface mount type for installation.
It is suitable for applications in automotive infotainment systems, display units, cameras, and various high-speed data interfaces.
