Nexperia Dual NPN + PNP Bipolar Transistor PBSS4160DPN,115, 1A 60V TSOP, Surface Mount

The Nexperia PBSS4160DPN,115 is a dual NPN + PNP bipolar junction transistor designed for high-efficiency switching and amplification in compact PCB assemblies. This model supports both NPN and PNP transistor functions, making it suitable for a variety of signal control scenarios in digital and analog applications.

With a maximum DC collector current of 1A and a collector-emitter voltage rated at 60V, the PBSS4160DPN,115 meets the demands of modern industrial, automotive, and commercial electronics requiring robust electrical performance and efficient operation. Its compact 6-pin TSOP package allows easy surface-mount integration in densely packed circuit boards.

Key electrical attributes include a low collector-emitter saturation voltage, reducing heat generation and improving efficiency during switching operations. The transistor offers a maximum power dissipation of 700mW and a high transition frequency of 220MHz, supporting rapid signal processing and data throughput for advanced circuit designs.

The device is designed to operate reliably over a wide temperature range, from -65°C to 150°C, making it ideal for industrial controls, automotive electronic control units (ECUs), manufacturing automation systems, and advanced digital electronics. Minimum DC current gain of 100 ensures consistent amplification and signal integrity across applications.

PBSS4160DPN,115 meets automotive standard AEC-Q101, providing proven quality and reliability for automotive-grade designs. The transistor configuration is isolated, further enhancing versatility and safety in high-performance electronic assemblies. The part measures 2.9mm in length, 1.5mm in width, and 1mm in height, well-suited for space-constrained designs and portable devices.

Typical industrial use cases include switching, amplification in digitized control systems, consumer electronics, laboratory instrumentation, and communications equipment. Its low saturation voltage and high collector current make it excellent for efficient circuit management and minimizes power losses throughout operation.

Supports both NPN and PNP configurations for multi-functional design applications. High maximum collector current and voltage ratings guarantee robust performance. Low saturation voltage reduces overall power loss and heat output.

Automotive AEC-Q101 standard ensures reliability and extended service life. Compact TSOP package is ideal for space-limited PCBs. Wide temperature tolerance for operation in harsh environments. Good current gain, fast transition frequency, and isolated configuration.
