Wurth Elektronik WR-PHD Series Straight Through Hole PCB Socket 24-Contact 2.54 mm Pitch Gold-Plated THT Single 61302411821

The Wurth Elektronik 61302411821 straight through hole PCB socket from the WR-PHD Series is an advanced connector designed to provide robust board-to-board connectivity in electronic assemblies. With its 24-contact single row configuration and a compact 2.54 mm pitch, it accommodates space-constrained circuit layouts while ensuring consistent and reliable electrical performance.

This high-performance socket features THT (Through Hole Technology) for stable mounting and a straight orientation, making it easy to align with mating components during assembly. Rated to handle up to 500 volts and supporting 3 amps of current per contact, it is well suited for power and signal applications across a variety of electronic systems.

The housing is manufactured from black polybutylene terephthalate (PBT) with a UL94-V0 flammability rating, offering both mechanical strength and high resistance to heat and fire, which is essential for safety compliance in industrial and laboratory environments. Inside, the connector employs gold-plated copper alloy contacts for optimal conductivity, minimal contact resistance, and superior corrosion resistance, helping to ensure stable operation over extended lifetimes.

The WR-PHD Series socket supports applications in industrial automation, instrumentation, embedded system designs, and high-reliability electronics. It provides a female contact system and is ideal for board-to-board connections where single-row configurations are required. The connector withstands temperature extremes from -40°C up to 105°C, functioning reliably even in harsh or thermally demanding use cases.

Ease of solder termination and its board-to-board mounting system further simplify the assembly process for manufacturers. The gold plating on the contacts improves wear characteristics, especially in environments with repeated mating/unmating cycles, while the socket's robust construction makes it especially useful in technical and electrical applications where performance and dependability are prioritized.

This product is commonly used in circuit board manufacturing, electronic equipment assembly, automation control panels, and other commercial and industrial electronics requiring consistent and durable PCB connectivity. Explore more board-to-board and PCB connection solutions in the Wurth Elektronik WR-PHD series and related PCB Socket categories on EnvMart.
