Epson 25 MHz Surface Mount Crystal Unit FA-238 Series ±50 ppm 18pF 4-Pin 3.2x2.5x0.7mm Q22FA2380014312

Epson Q22FA2380014312 is a miniature surface mount crystal unit from the FA-238 series, designed with a compact ceramic case measuring 3.2 mm length, 2.5 mm width, and 0.7 mm height. It operates at a standard frequency of 25 MHz with a frequency tolerance of ±50 ppm, ensuring precise timing and frequency stability crucial for electronic applications.

Its fundamental overtone order and 60 Ω series resistance make it particularly suited for communication and computing modules such as mobile phones, Bluetooth devices, and WLAN ISM band radios. The crystal features an 18 pF load capacitance and a 4-pin surface mount configuration for reliable PCB integration.

Designed to withstand operating temperatures from -40°C up to 85°C, this crystal unit is certified compliant with RoHS and REACH directives, supporting environmentally friendly electronic manufacturing.

The compact FA-238 package provides a low-profile design ideal for space-constrained applications. This product is especially recommended for industrial electronics, telecommunications, and embedded system timing solutions.

Compact FA-238 package measuring 3.2 x 2.5 x 0.7 mm for space-efficient PCB design. 25 MHz standard frequency with ±50 ppm tolerance ensuring precise timing. Fundamental overtone order with 60 Ω series resistance for reliable operation.

Wide operating temperature range from -40°C to 85°C for harsh environments. 18 pF load capacitance optimized for frequency stability. Four-pin surface mount configuration for easy mounting and soldering. RoHS and REACH compliant for environmentally safe manufacturing.

Ideal for mobile, Bluetooth, WLAN, and MPU clock applications.
