Abracon 12 MHz Crystal Unit ±20 ppm, Surface Mount, 4-Pin, 18pF, 1 mm Height, 3.2 mm × 2.5 mm ABM8G-12.000MHZ-18-D2Y-T
Specifications
| Country of Origin | India |
|---|---|
| Brand | Abracon |
| Height | 1mm |
| Length | 3.2mm |
| Model | ABM8G-12.000MHZ-18-D2Y-T |
| Packaging | Tape & Reel |
| Width | 2.5mm |
| Mount Type | Surface |
| Series | ABM8G |
| Maximum Operating Temperature | 85°C |
| Package Type | Surface Mount |
| Minimum Operating Temperature | -40°C |
| Standards/Approvals | REACH, RoHS |
| Pin Count | 4 |
| Standard Frequency | 12MHz |
| Load Capacitance | 18pF |
| Series Resistance | 120Ω |
| RS PRO 12 MHz Crystal ±20 ppm SMT 4-Pin 0.7 mm 3.2 mm 2.5mmRS Stock No. | 144-5056Brand: RS PRO |
Key Features
- 12 MHz standard frequency for timing applications.
- ±20 ppm frequency tolerance offers high accuracy.
- Surface mount package with glass-sealed enclosure enhances reliability.
- 4-pin configuration suitable for PCB mounting in electronic circuits.
- 18pF load capacitance ensures stable oscillation.
- Suitable for high-density, thin equipment requiring tight tolerance.
- IR reflow compatible for automated assembly processes.
Product Description
Abracon ABM8G-12.000MHZ-18-D2Y-T is a precision crystal unit designed for timing and frequency control applications in modern electronic circuits. Operating at a standard frequency of 12 MHz with a tight ±20 ppm frequency tolerance, this unit provides dependable performance for high-density, accuracy-sensitive designs.
The crystal features a surface mount package that is glass sealed, ensuring high reliability and stable operation even in environments subjected to thermal cycling and mechanical stress. Its compact dimensions (3.2 mm × 2.5 mm × 1 mm) make it ideal for thin equipment and space-constrained boards, such as modems, communication devices, PCMCIA and wireless applications.
With an 18pF specified load capacitance and a frequency stability of ±30 ppm, the device offers excellent oscillation characteristics. The 4-pin configuration provides straightforward PCB integration, and the package is IR reflow compatible, allowing for automated, high-efficiency manufacturing and assembly processes.
The Crystal Unit achieves a high degree of tolerance and stability, making it suitable for critical timing requirements in modems, networking, and test equipment, as well as other applications requiring accurate clock signals. The glass-sealed package is optimized for reliability and thermal performance, supporting an operating temperature range from -40°C to 85°C.
With a series resistance of 120Ω, the ABM8G-12.000MHZ-18-D2Y-T supports high-density deployment and ensures consistent signal integrity. It is a low-cost version of the ABM8 crystal series, designed for volume production environments, and adheres to REACH and RoHS standards.
Typical industrial applications include telecommunications, laboratory instrumentation, embedded computing, and automated test equipment. Explore EnvMart’s selection of Abracon timing solutions and browse more crystal and oscillator units for your electronic design needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The standard frequency of this crystal unit is 12 MHz, making it suitable for timing applications in electronic circuits.
It has a frequency tolerance of ±20 ppm, which ensures high accuracy for timing applications.
The dimensions of this crystal unit are 3.2 mm in length, 2.5 mm in width, and 1 mm in height, making it compact for space-constrained designs.
The load capacitance specified for this model is 18 pF, which contributes to its stable oscillation characteristics.
The operating temperature range for the ABM8G-12.000MHZ-18-D2Y-T is from -40°C to 85°C, suitable for various environments.
This model features a surface mount configuration, allowing for easy integration into printed circuit boards (PCBs).
This crystal unit has a 4-pin configuration, which facilitates straightforward connections on PCBs.
The crystal unit adheres to REACH and RoHS standards, ensuring compliance with environmental regulations.
The series resistance of the ABM8G-12.000MHZ-18-D2Y-T is 120Ω, which helps maintain signal integrity in high-density applications.
Yes, it is IR reflow compatible, making it suitable for automated manufacturing and assembly processes.
This model is suitable for telecommunications, laboratory instrumentation, embedded computing, and automated test equipment, among other timing-sensitive applications.
It is packaged in tape and reel format, which is ideal for automated assembly and efficient handling during manufacturing.
