Abracon 24 MHz Crystal Unit, ±30 ppm, Surface Mount, 4-Pin, 10pF Load, 3.2 x 2.5 x 1 mm, ABM8G-24.000MHZ-B4Y-T
Specifications
| Country of Origin | China |
|---|---|
| Brand | Abracon |
| Height | 1mm |
| Length | 3.2mm |
| Model | ABM8G-24.000MHZ-B4Y-T |
| Packaging | Tape & Reel |
| Width | 2.5mm |
| Mount Type | Surface |
| Series | ABM8G |
| Maximum Operating Temperature | 70°C |
| Package Type | Surface Mount |
| Minimum Operating Temperature | -20°C |
| Standards/Approvals | REACH, RoHS |
| Pin Count | 4 |
| Standard Frequency | 24MHz |
| Load Capacitance | 10pF |
| Series Resistance | 60Ω |
Key Features
- Accurate 24 MHz frequency stability for reliable timing.
- Surface mount package with glass seal ensures robust performance.
- ±30 ppm frequency tolerance and stability for precise operation.
- 4-pin configuration allows easy integration onto PCBs.
- Low-profile size with 3.2 mm length, 2.5 mm width, and 1 mm height.
- 10 pF load capacitance suitable for modern electronics designs.
- Wide operating temperature range from -20°C to 70°C.
- REACH and RoHS compliant for environmental safety.
Product Description
The Abracon ABM8G-24.000MHZ-B4Y-T is a precision 24 MHz surface mount crystal unit engineered to deliver stable and accurate frequency control for a wide range of electronic applications. As part of the ABM8G series, this crystal is optimized for high-density PCB layouts in products where size constraints are critical.
Featuring a glass-sealed package, the unit is highly reliable and supports operation in elevated temperature environments. It is supplied in a 4-pin surface mount configuration for streamlined assembly and secure mounting on modern electronic boards.
With ±30 ppm frequency tolerance and ±30 ppm stability, the ABM8G-24.000MHZ-B4Y-T ensures precise clock signals essential for microcontrollers, communications modules, and testing devices. Its low height profile (just 1 mm) caters to compact and portable devices.
The 10 pF load capacitance suits a variety of circuit designs, making it a versatile choice for engineers. The component’s robust performance is maintained across a broad temperature range, from -20°C to 70°C, and the glass-sealed enclosure enhances resistance to moisture and mechanical stress.
Compliance with REACH and RoHS standards guarantees safety and environmental responsibility, and its packaging in tape & reel format makes it ideal for automated production lines.
Abracon’s ABM8G-24.000MHZ-B4Y-T crystal is used in modems, wireless communications, PCMCIA interfaces, and various industrial, laboratory, and test equipment where precision timing and stability are required. Applications extend to manufacturing, research, and commercial electronics.
Product highlights include high frequency accuracy, compact dimensions, and suitability for reflow solder processes. This crystal unit provides a cost-effective timing solution backed by Abracon’s expertise in frequency control products.
Explore more Abracon Crystal Units and advanced frequency components in the Electronics Components category on EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The frequency of this crystal unit is 24 MHz, providing accurate timing for various electronic applications.
The dimensions of the Abracon ABM8G-24.000MHZ-B4Y-T are 3.2 mm in length, 2.5 mm in width, and 1 mm in height.
This crystal unit has a load capacitance of 10 pF, making it suitable for various circuit designs.
The operating temperature range for the Abracon ABM8G-24.000MHZ-B4Y-T is from -20°C to 70°C.
The frequency tolerance of this model is ±30 ppm, ensuring precise operation in timing applications.
The Abracon ABM8G-24.000MHZ-B4Y-T is packaged in tape & reel format, which is ideal for automated production lines.
This model utilizes a surface mount configuration, allowing for easy integration onto printed circuit boards (PCBs).
The series resistance of the Abracon ABM8G-24.000MHZ-B4Y-T is 60Ω, which is relevant for its performance in circuits.
This crystal unit complies with REACH and RoHS standards, ensuring environmental safety and responsibility.
The ABM8G-24.000MHZ-B4Y-T is suitable for use in modems, wireless communications, and various industrial and laboratory testing equipment.
This model features a 4-pin configuration, facilitating secure mounting and assembly on electronic boards.
The Abracon ABM8G-24.000MHZ-B4Y-T is part of the ABM8G series, optimized for high-density PCB layouts.
