Hongfa Europe GMBH Force Guided Relay Surface Mount DPDT 1-Pole 12V dc Coil Voltage HFA4/12-2H2DTGF
Specifications
| Country of Origin | China |
|---|---|
| Brand | Hongfa Europe GMBH |
| Height | 24mm |
| Length | 40mm |
| Model | HFA4/12-2H2DTGF |
| Depth | 13mm |
| Mount Type | Surface |
| Contact Material | Silver Alloy |
| Series | HFA4 |
| Maximum Operating Temperature | 85°C |
| Contact Configuration | DPDT |
| Minimum Operating Temperature | -40°C |
| Terminal type | PCB Terminal |
| Number of Poles | 1 |
| Coil Resistance | 400Ω |
| Coil Power | 360mW |
| Outline Dimensions | (40.0 x 13.0 x 24.0) mm |
| Isolation Coil To Contact | 10kV |
| Multi contact arrangements | 2NO+2NC |
| Low input power | 360mW |
| High insulation capability | 10kV surge voltage between input and output |
Key Features
- Features surface mount type for easy PCB integration.
- Contact configuration is double-pole double-throw (DPDT) ensuring versatile switching.
- Coil resistance is 400Ω with low coil power consumption of 360mW.
- Operates reliably between -40°C and 85°C operating temperatures.
- Uses PCB terminals and silver alloy contact material for durability.
- High insulation voltage of 10 kV between coil and contacts enhances safety.
- Supports multiple contact arrangements including 2NO+2NC for flexible applications.
- Compact outline dimensions approximately 40 x 13 x 24 mm suit various applications.
Product Description
Hongfa Europe GMBH HFA4/12-2H2DTGF force guided relay is a surface mount device with a 12V dc coil voltage, designed for precise control in industrial and electrical automation applications. It features a 1-pole, double-pole double-throw (DPDT) contact configuration enabling multiple connection options with mechanically linked contacts for safety and reliability in failsafe circuits.
This relay incorporates silver alloy contacts that guarantee low contact resistance and durability under frequent switching cycles. The coil resistance of 400Ω combined with a low coil power consumption of 360mW ensures energy efficiency during operation. Capable of operating within a wide temperature range from -40°C to 85°C, it is suitable for varied environmental conditions.
The relay's PCB terminal type eases mounting on printed circuit boards for compact system integration. Its high isolation voltage of 10 kV between coil and contacts provides robust insulation to withstand electrical surges, which is critical for maintaining system integrity.
Multiple contact arrangements including 2 Normally Open (NO) and 2 Normally Closed (NC) contacts allow flexible wiring configurations for complex control schemes. The compact outline dimensions of 40.0 x 13.0 x 24.0 mm enable installation in space-constrained environments.
This product is optimal for applications in industrial control, automation systems, signal conditioning circuits, and other electrical equipment requiring reliable force guided relay operation.
Features surface mount type for easy PCB integration. Contact configuration is double-pole double-throw (DPDT) ensuring versatile switching. Coil resistance of 400Ω offers stable operation. Low coil power consumption of 360mW improves energy efficiency.
Wide temperature operation from -40°C to 85°C. Silver alloy contact material enhances durability and conductivity. High isolation voltage of 10 kV for excellent insulation. Dimensions suitable for compact integration: 40 x 13 x 24 mm.
Supports multiple contact arrangements (2NO+2NC) for versatile use. Explore more Force Guided Relays and related electrical components at EnvMart to find the perfect fit for your industrial and automation needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The relay features a double-pole double-throw (DPDT) contact configuration, allowing for versatile switching options.
This model operates with a coil voltage of 12V DC.
The outline dimensions of this relay are approximately 40mm in length, 13mm in depth, and 24mm in height.
The coil resistance is 400Ω, which contributes to its stable operation.
The coil power consumption is 360mW, ensuring energy efficiency during operation.
It operates reliably within a temperature range of -40°C to 85°C.
This model uses PCB terminals, facilitating easy mounting on printed circuit boards.
The relay has a high isolation voltage of 10 kV between the coil and contacts, enhancing safety.
The contacts are made of silver alloy, which provides low contact resistance and durability.
It supports multiple contact arrangements, including 2 Normally Open (NO) and 2 Normally Closed (NC) contacts.
The relay is manufactured in China.
This relay is suitable for applications in industrial control, automation systems, and signal conditioning circuits.
