Hongfa Europe GMBH PCB Signal Relay 12V dc Coil 2A DPDT HFD2/012-S-L1-D

Free Delivery in India | Lowest Global Shipping Charges

Hongfa Europe GMBH PCB Signal Relay 12V dc Coil 2A DPDT HFD2/012-S-L1-D

Name: Hongfa Europe GMBH PCB Signal Relay 12V dc Coil 2A DPDT HFD2/012-S-L1-D
Brand: Hongfa Europe GMBH
SKU: 420526
Price: 4.49 USD
Availability: InStock



Category Signal Relay Brand Hongfa Europe GMBH Condition New

Specifications

Country of Origin	China
Brand	Hongfa Europe GMBH
Height	10.6mm
Length	20.2mm
Model	HFD2/012-S-L1-D
Width	10.2mm
Mount Type	PCB
Contact Material	Silver
Series	HFD2
Maximum Operating Temperature	85°C
Contact Configuration	DPDT
Minimum Operating Temperature	-40°C
Switching Current	2A
Terminal type	PCB Terminal
Contact Resistance	100mΩ
Standards/Approvals	RoHS
Coil Resistance	1920Ω
Coil Voltage	12V dc
Switching DC Voltage	220V dc
Switching AC Voltage	250V ac
Coil Power	75mW
Switching Power	90W

Key Features

Coil voltage is 12V DC ensuring low power consumption.
Double pole double throw (DPDT) contact configuration allows versatile circuit control.
Rated switching current of 2A provides reliable electrical performance.
Switching voltages support up to 250V AC and 220V DC operation.
Compact dimensions of 20.2mm length, 10.6mm height, and 10.2mm width enable PCB mounting flexibility.
Coil power is low at 75mW facilitating energy efficiency.
Service temperature range from -40°C to 85°C for robust industrial application.
Silver contact material with gold coating ensures corrosion resistance and long contact life.

Product Description

Hongfa Europe GMBH HFD2/012-S-L1-D is a subminiature dual pole double throw (DPDT) PCB signal relay designed for industrial and electronic control applications. It operates with a 12V DC coil with a coil power of 75mW, ensuring efficient energy use. The relay features low mounting height and compact form factor of 20.2mm x 10.2mm x 10.6mm, making it ideal for PCB mounting in various electrical devices.

This relay provides a switching current rating of 2A, supporting switching voltages up to 250V AC and 220V DC, suitable for a range of control circuit scenarios. Silver contact material with gold coating enhances reliability and longevity by reducing contact resistance and corrosion effects. The relay is designed for automatic manufacturing environments with epoxy sealing for wave soldering compatibility.

Operating temperature spans from -40°C to 85°C, providing durability in harsh conditions. The PCB terminal type and DIP mounting facilitate easy installation and replacement on printed circuit boards. The relay is commonly used in automotive electronics, industrial control systems, and other signal relay applications requiring precise switching and high durability.

Coil voltage is 12V DC ensuring low power consumption. Double pole double throw (DPDT) contact configuration allows versatile circuit control. Rated switching current of 2A provides reliable electrical performance. Switching voltages support up to 250V AC and 220V DC operation.

Compact dimensions enable flexibility in PCB mounting. Low coil power consumption of 75mW. Wide operating temperature range from -40°C to 85°C. Silver contacts with gold coating provide high reliability. Epoxy sealed for automatic wave soldering and cleaning processes.

DIP terminal type compatible with 16 pin IC sockets.

This Signal Relay is engineered for use across electronics, automation, industrial control, automotive, and manufacturing sectors. Its reliable switching characteristics and compact design make it an essential component for PCB-mounted control systems. Browse EnvMart's extensive relay catalog for related industrial electrical components.
