Hongfa Europe GMBH PCB Power Relay, 5V DC Coil, 10A Switching Current, DPDT HF140FF/005-2ZSTF
Specifications
| Country of Origin | China |
|---|---|
| Brand | Hongfa Europe GMBH |
| Height | 26.3mm |
| Length | 29mm |
| Model | HF140FF/005-2ZSTF |
| Width | 13mm |
| Mount Type | PCB |
| Contact Material | Silver Alloy |
| Series | HF140FF |
| Maximum Operating Temperature | 85°C |
| Contact Configuration | DPDT |
| Minimum Operating Temperature | -40°C |
| Switching Current | 10A |
| Terminal type | PCB Pin |
| Contact Resistance | 50mΩ |
| Standards/Approvals | RoHS |
| Coil Resistance | 47Ω |
| Coil Voltage | 5V dc |
| Switching DC Voltage | 30V dc |
| Switching AC Voltage | 250V |
| Coil Power | 530mW |
Key Features
- Equipped with a 5V DC coil for actuation.
- Double Pole Double Throw (DPDT) contact configuration ensures versatile switching.
- Capable of switching currents up to 10A and AC voltage up to 250V.
- Silver alloy contacts provide durable and low resistance performance.
- Designed for temperatures ranging from -40°C to 85°C for industrial use.
- Provides isolation voltage of 5KV between coil and contacts.
- Plastic sealed type construction for environmental protection.
- Durable up to 10 million mechanical cycles, ensuring long operational life.
Product Description
Hongfa Europe GMBH HF140FF/005-2ZSTF PCB Power Relay is a high-performance, non-latching DPDT electromagnetic relay designed for PCB mounting. It features a 5V DC coil that actuates the relay, allowing it to switch high currents up to 10A and switching AC voltages up to 250V with silver alloy contacts, ensuring low contact resistance and reliable operation.
This power relay supports a wide temperature range from -40°C to 85°C, making it suitable for harsh industrial, automotive, and automation environments. The relay's coil resistance of 47Ω and coil power consumption of 530mW balance performance and energy efficiency.
Isolation voltage between the coil and contacts reaches up to 5KVAC, providing strong electrical isolation and safety in control circuits. The relay's compact size with dimensions 29mm length, 26.3mm height, and 13mm width fits standard PCB layouts.
The plastic sealed type design offers protection against dust and contaminants, enhancing durability. This relay is environmentally friendly, complying with RoHS standards, and is rated for up to 10 million mechanical operations, guaranteeing extended service life.
Equipped with a 5V DC coil for actuation. Double Pole Double Throw (DPDT) contact configuration ensures versatile switching. Capable of switching currents up to 10A and AC voltage up to 250V. Silver alloy contacts provide durable and low resistance performance.
Designed for temperatures ranging from -40°C to 85°C for industrial use. Provides isolation voltage of 5KV between coil and contacts. Plastic sealed type construction for environmental protection. Durable up to 10 million mechanical cycles, ensuring long operational life.
Suitable for automotive and control device applications in industrial automation. RoHS compliant, ensuring environmentally friendly product standards.
This PCB power relay is ideal for applications in industrial automation, automotive control systems, and other control device requirements where reliable switching and electrical isolation are critical. Its compact design and performance characteristics make it an excellent choice for demanding environments.
Explore more Power Relays and related components at EnvMart for your electronic and electrical design needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model can switch currents up to 10A.
It features a Double Pole Double Throw (DPDT) contact configuration, allowing for versatile switching options.
The relay operates with a 5V DC coil voltage.
It is capable of switching AC voltages up to 250V.
The dimensions are 29mm in length, 26.3mm in height, and 13mm in width.
It is designed to operate in temperatures ranging from -40°C to 85°C.
The contacts are made of silver alloy, which helps ensure low contact resistance and reliable performance.
The coil resistance is 47Ω.
The isolation voltage is rated at 5KVAC, providing strong electrical isolation.
This model is rated for up to 10 million mechanical cycles, ensuring a long operational life.
It is RoHS compliant, ensuring it meets environmentally friendly product standards.
This relay is designed for PCB mounting, making it suitable for various electronic applications.
