Panasonic PCB Force Guided Relay 5V DC Coil Voltage 2-Pole DPDT SF2D5D
Specifications
| Country of Origin | Czech Republic |
|---|---|
| Brand | Panasonic |
| Height | 16mm |
| Operating Temperature Range | -40°C to +70°C |
| Length | 53.3mm |
| Model | SF2D5D |
| Depth | 25mm |
| Mount Type | PCB |
| Contact Material | Gold Plated |
| Series | SF2D |
| Maximum Operating Temperature | 70°C |
| Contact Configuration | DPDT |
| Minimum Operating Temperature | -40°C |
| Terminal type | Solder |
| Number of Poles | 2 |
| Coil Resistance | 50Ω |
| Coil Power | 500mW |
| Maximum Switching Voltage | 400V |
| Isolation Coil To Contact | 2.5kVrms |
| Panasonic Non-Latching Relay, 10A Switching CurrentBrand | Panasonic |
Key Features
- The relay features gold-plated AgSnO2 contacts with Au flash for reliable switching performance.
- Coil resistance of 50Ω and coil power consumption of 500mW ensure efficient operation.
- Offers maximum switching voltage capacity up to 400V for versatile industrial use.
- Operates reliably across a temperature range from -40°C to +70°C, suitable for demanding environments.
- Compact PCB mount design with solder terminals facilitates easy integration in electronic assemblies.
- High isolation between coil and contacts of 2.5 kVrms ensures safety and noise immunity.
- Compliant with EN50205 Type A and IEC60664-1 III/4kV standards, approved by cUL, TUV, and SEV for safety applications.
- Suitable for automation, electrical, industrial safety, railway, medical equipment, and other critical installations.
Product Description
Panasonic SF2D5D PCB Force Guided Relay is a high-reliability safety relay designed for PCB mounting with 5V DC coil voltage and 2-pole double pole double throw (DPDT) contact configuration. It is primarily used in safety-critical machinery, electrical panels, and industrial installations where strict safety standards must be met.
This relay ensures force guided, safe switching of contacts with gold-plated AgSnO2 contact material enhanced by an Au flash, providing excellent durability and resistance to wear. Operating efficiently at coil power of 500mW with a coil resistance of 50Ω, it supports control circuits requiring sensitive and low-power inputs.
The SF2D5D model supports a maximum switching voltage of 400V, suitable for a wide range of industrial and automation applications. Its operation is reliably maintained within the broad temperature range of -40°C to +70°C, allowing deployment in harsh environmental conditions, such as outdoor machinery or HVAC controls.
Its compact footprint (53.3 mm length, 25 mm depth, and 16 mm height) and solder terminal mounting type facilitate straightforward PCB integration without requiring additional mounting hardware. The coil-to-contact isolation rated at 2.5 kVrms provides excellent electrical isolation and protects against voltage surges and interference.
Compliant with international standards EN50205 Type A and IEC60664-1 III/4kV, and certified by cUL, TUV, and SEV, it meets rigorous safety regulations required in presses, combustion engines, railway systems, medical devices, and other automated equipment requiring reliable safety relays.
Gold-plated AgSnO2 contacts with Au flash for durability. Coil power of 500mW with a 50Ω coil resistance for efficient control. Max switching voltage of 400V for diverse applications. Operating temperature range from -40°C to +70°C for harsh environments.
Compact PCB mount form factor with solder terminals. High coil-to-contact isolation voltage of 2.5 kVrms. Complies with EN50205 Type A and IEC60664-1 standards. Approvals from cUL, TUV, and SEV ensure safety compliance. Ideal for industrial automation, railway, medical, and safety-critical systems.
Choose Panasonic SF2D5D PCB Force Guided Relay for high safety and reliability in your automation and control systems. Browse our full range of relays and Force Guided Relays on EnvMart for your industrial electrical needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The relay operates with a coil voltage of 5V DC.
It supports a maximum switching voltage capacity of 400V, making it suitable for various industrial applications.
This model operates reliably within a temperature range of -40°C to +70°C.
The relay features a 2-pole double pole double throw (DPDT) contact configuration.
The coil resistance is 50Ω, and the coil power consumption is 500mW.
The isolation between the coil and contacts is rated at 2.5 kVrms, providing excellent electrical isolation.
It is designed for PCB mounting with solder terminals, facilitating easy integration into electronic assemblies.
It complies with EN50205 Type A and IEC60664-1 III/4kV standards, and is approved by cUL, TUV, and SEV.
The contacts are made of gold-plated AgSnO2 material with an Au flash for enhanced durability and wear resistance.
The relay has dimensions of 53.3 mm in length, 25 mm in depth, and 16 mm in height.
It is suitable for automation, electrical, industrial safety, railway, medical equipment, and other critical installations.
The relay is manufactured in the Czech Republic.
