TDK SIMID 2220 Unshielded Wirewound Surface Mount Inductor with Ferrite Core 220 μH ±10 % 330 mA Idc Q:20 B82442T1224K000
Specifications
| Country of Origin | Hungary |
|---|---|
| Brand | TDK |
| Height | 5mm |
| Length | 5.6mm |
| Model | B82442T1224K000 |
| Depth | 5mm |
| Packaging | Tape & Reel |
| Series | SIMID |
| Maximum Operating Temperature | 150°C |
| Minimum Operating Temperature | -55°C |
| Core Material | Ferrite |
| Inductance | 220μH |
| Standards/Approvals | RoHS, JEDEC J-STD 020D, AEC-Q200 |
| Package/Case | 2220 |
| Maximum DC Current | 330mA |
| Maximum DC Resistance | 2.21Ω |
| Inductance Tolerance | ±10 % |
| Termination Style | Solder |
| Maximum Self Resonant Frequency | 3.9MHz |
| Minimum Quality Factor | 20 |
| Inductor Construction | Wirewound |
| Automotive Standard | AEC-Q200 |
Key Features
- Constructed with a ferrite drum core and wirewound winding for optimal performance.
- Maximum DC resistance of 2.21 Ω ensuring efficient current flow.
- High-quality factor of minimum 20 for reliable filtering and coupling.
- Suitable for operating temperatures ranging from -55°C to 150°C.
- Designed for automotive applications conforming to AEC-Q200 standards.
- Package size 2220 with dimensions 5.6 mm length, 5 mm height, and 5 mm depth.
- Termination style is solder, compatible with lead-free reflow soldering.
- Maximum self-resonant frequency of 3.9 MHz for high-frequency use.
Product Description
TDK B82442T1224K000 SIMID 2220 unshielded wirewound Surface Mount Inductor with a ferrite core provides 220 μH inductance with ±10 % tolerance and a maximum DC current rating of 330 mA. It is engineered using a ferrite drum core and laser-welded wirewound winding, encased in flame-retardant molding for robustness.
This inductor supports demanding industrial and automotive electronics applications, including filtering of supply voltages, coupling, decoupling, DC to DC converters, switch-mode power supplies, telecommunications, and consumer electronics. Its operation is reliable in a temperature range from -55°C to +150°C.
The product complies with AEC-Q200 automotive standards and JEDEC J-STD 020D lead-free reflow soldering requirements, making it suitable for automotive and industrial environments. It features a maximum DC resistance of 2.21 Ω and a minimum quality factor of 20, ensuring performance stability at frequencies up to 3.9 MHz.
Packaging is tape and reel, suitable for automated surface mount technology assembly. The inductor is halogen-free and RoHS compatible, supporting environmentally sustainable manufacturing processes. Core material is ferrite, and the termination style is solder.
Typical industrial use cases include electronics manufacturing, automotive systems, telecommunications, and power management in commercial and industrial equipment. Constructed with ferrite drum core and wirewound winding.
Rated voltage and current suitable for high reliability applications. Compliant with automotive and environmental standards. Compact 2220 case size fits modern surface mount assembly lines. Performance verified over wide temperature range.
Explore a comprehensive range of inductors and electronic components at EnvMart for industrial and manufacturing use.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model has an inductance value of 220 μH with a tolerance of ±10%.
The maximum DC current rating for this inductor is 330 mA.
The dimensions of this inductor are 5.6 mm in length, 5 mm in height, and 5 mm in depth.
The maximum DC resistance is 2.21 Ω, ensuring efficient current flow.
The maximum self-resonant frequency is 3.9 MHz, suitable for high-frequency applications.
It can operate in a temperature range from -55°C to 150°C.
The termination style is solder, and it is compatible with lead-free reflow soldering according to JEDEC J-STD 020D standards.
It complies with AEC-Q200 automotive standards and is RoHS compliant.
The core material used is ferrite, which contributes to its performance characteristics.
It is suitable for automotive and industrial electronics applications, including filtering, coupling, and DC to DC converters.
The inductor is packaged in tape and reel format, making it suitable for automated surface mount technology assembly.
The minimum quality factor is 20, ensuring reliable filtering and coupling performance.
