Nexperia Resistor-Equipped PNP Transistor, -100 mA DC Collector Current, -50 V Collector Emitter Voltage, 3-Pin PDTA143XQCZ

Nexperia PDTA143XQCZ resistor-equipped transistor is a reliable 3-pin PNP device specifically designed for electronic and power semiconductor applications. It features a maximum DC collector current of -100 mA with a collector emitter voltage rating of -50 V, making it ideal for switching and amplification purposes.

Packaged in an ultra-compact DFN1412D-3 plastic package with side-wettable flanks and a low profile of 0.5 mm, this transistor supports surface mount assembly ensuring high efficiency in automated production lines and suitability for automatic optical inspection (AOI) of solder joints.

Built-in resistors reduce the number of discrete components required in a circuit, simplifying design while minimizing board space and assembly costs. The transistor can operate reliably across a broad temperature range from -55°C to 150°C, meeting the stringent AEC-Q101 automotive standard and RoHS environmental compliance.

This device is widely used in digital applications such as controlling IC inputs and switching loads, offering a cost-effective alternative to the BC857 series transistor. Its maximum emitter base voltage of -10 V enhances the protection of associated circuitry.

Ultra small DFN1412D-3 plastic package with side-wettable flanks for surface mounting. Built-in resistors simplify circuit design and reduce component count. Low package height of 0.5 mm suitable for automated optical inspection of solder joints.

Capable of operating temperature ranging from -55°C to 150°C, suitable for automotive and industrial applications. Meets RoHS compliance and AEC-Q101 automotive standard. Ideal for controlling IC inputs and switching loads in digital electronic circuits.

Cost-effective alternative to BC857 series in digital applications. 3-pin PNP transistor polarity with surface mount package type. Max emitter base voltage of -10 V enhances circuit protection. Designed to reduce pick and place costs with leadless surface mount technology.

This bipolar resistor-equipped transistor is suitable for various industries including industrial automation, automotive electronics, manufacturing, and digital electronics. It delivers efficient performance in compact electronic assemblies requiring reliable switch and amplification functions.
