| Country of Origin | India |
|---|---|
| Brand | Nexperia |
| Model | PDTA123JQC-QZ |
| Mount Type | Surface |
| Series | PDTA123J |
| Maximum Operating Temperature | 150°C |
| Package Type | DFN1412D-3 |
| Minimum Operating Temperature | -55°C |
| Standards/Approvals | RoHS |
| Pin Count | 3 |
| Maximum Collector Emitter Voltage Vceo | -50V |
| Transistor Polarity | PNP |
| Maximum Emitter Base Voltage VEBO | -10V |
| Automotive Standard | AEC-Q101 |
| Maximum DC Collector Current Idc | -100mA |
| Transistor Configuration | PNP |
The Nexperia PDTA123JQC-QZ is a resistor-equipped PNP transistor designed for use in modern electronic circuits requiring efficient switching and control. It features an ultra-small DFN1412D-3 (SOT8009) plastic package with side-wettable flanks, enabling reliable surface mount assembly and enhanced automatic optical inspection.
This device offers a maximum DC collector current of 100 mA and maximum collector-emitter voltage of 50 V, supporting robust performance in low power switching applications. The integrated resistors simplify circuit design by reducing the number of discrete components needed, thus lowering overall component count and assembly costs.
With an operating temperature range from -55 °C to 150 °C and automotive standard AEC-Q101 compliance, this transistor is suitable for a variety of industrial, automotive, and digital applications where temperature stability and reliability are critical.
Typical usages include controlling IC inputs, switching loads in consumer electronics, and embedded digital applications where space-saving and cost efficiency are priorities. Built-in resistors simplify circuit design and reduce component count.
Supports maximum DC collector current of 100 mA. Rated for maximum collector-emitter voltage of 50 volts. Low package height of 0.5 mm enables compact device assemblies. Operational temperature range from -55 to 150 °C ensures reliability in harsh environments.
Complies with RoHS and meets automotive AEC-Q101 standards. Side-wettable flanks facilitate automated solder joint inspection by AOI systems. 3-pin leadless surface mount design reduces pick-and-place costs. Cost-effective alternative to BC857 series in digital applications.
Ideal for switching loads and controlling IC inputs with enhanced integration. Complete your semiconductor components with Nexperia's broad range at EnvMart.
