| Country of Origin | India |
|---|---|
| Brand | Nexperia |
| Model | PDTA143XQB-QZ |
| Mount Type | Surface |
| Series | PDTA143X |
| Maximum Operating Temperature | 150°C |
| Package Type | DFN1110D-3 |
| Minimum Operating Temperature | -55°C |
| Standards/Approvals | RoHS |
| Pin Count | 3 |
| Maximum Collector Emitter Voltage Vceo | -50V |
| Transistor Polarity | PNP |
| Maximum Emitter Base Voltage VEBO | -10V |
| Automotive Standard | AEC-Q101 |
| Maximum DC Collector Current Idc | -100mA |
| Transistor Configuration | PNP |
Nexperia PDTA143XQB-QZ resistor-equipped transistor is a PNP bipolar transistor designed for compact, low-power switching electronic applications. It is housed in an ultra-small 3-pin DFN1110D-3 surface mount plastic package with side-wettable flanks and low 0.5 mm profile height, making it ideal for dense PCB layouts.
This transistor supports a maximum DC collector current of 100 mA and has a maximum collector-emitter voltage rating of 50 V, enabling reliable operation in low to medium current switching scenarios. Its built-in resistors reduce the need for external components, simplifying circuit design and lowering bill of materials costs.
The device's operating temperature range from −55°C to 150°C makes it suitable for use in automotive and industrial environments. It meets the AEC-Q101 automotive qualification standard, ensuring robustness under demanding conditions.
Typical applications include controlling digital IC inputs, switching loads in digital circuits, and serving as a cost-effective alternative to the BC857 series for digital switching needs.
This transistor is designed for surface mount technology (SMT) processes, with side-wettable flanks compatible with automatic optical inspection (AOI) of solder joints to enhance manufacturing quality control.
Ultra-small DFN1110D-3 package reduces PCB space requirements. 100 mA collector current capacity for efficient load switching. Built-in resistors simplify design and reduce components. Low profile (0.5 mm) suitable for compact electronic devices.
Automotive grade with AEC-Q101 certification ensures reliability. Wide operating temperature range from -55°C to 150°C. Optimized for digital signal switching applications. Compatible with AOI for improved manufacturing inspection.
This resistor-equipped transistor is ideal for use in industrial, automotive, telecommunications, and consumer electronics applications requiring reliable PNP transistor switching in constrained PCB spaces. EnvMart offers this product for engineers and designers looking to optimize circuit design and minimize component count.
