Nexperia 40 V 3 A Low Forward Voltage Schottky Diode 2-Pin SOD-128 PMEG4030ETP,115

Free Delivery in India | Lowest Global Shipping Charges

Nexperia 40 V 3 A Low Forward Voltage Schottky Diode 2-Pin SOD-128 PMEG4030ETP,115

Name: Nexperia 40 V 3 A Low Forward Voltage Schottky Diode 2-Pin SOD-128 PMEG4030ETP,115
Brand: Nexperia
SKU: 398256
Price: 0.32 USD
Availability: InStock



Category Schottky Diodes & Rectifiers Brand Nexperia Condition New

Specifications

Country of Origin	India
Brand	Nexperia
Height	1.1mm
Length	4mm
Model	PMEG4030ETP,115
Width	2.7mm
Mount Type	Surface
Series	PMEG4030ETP
Maximum Operating Temperature	175°C
Package Type	SOD-128
Minimum Operating Temperature	-55°C
Pin Count	2
Automotive Standard	AEC-Q101
Maximum Continuous Forward Current If	3A
Peak Reverse Repetitive Voltage Vrrm	40V
Diode Configuration	Single
Rectifier Type	Schottky
Peak Reverse Current Ir	23mA
Peak Non-Repetitive Forward Surge Current Ifsm	50A
Maximum Forward Voltage Vf	490mV
Average forward current	IF(AV) ≤ 3 A
Reverse voltage	VR ≤ 40 V

Key Features

Operates with a maximum continuous forward current of 3 A.
Maximum repetitive reverse voltage of 40 V ensures robust blocking capability.
Schottky diode configuration provides low forward voltage drop of 490 mV.
Peak reverse current of only 23 mA enhances efficiency.
Thermally rated for operation up to 175°C junction temperature.
Designed with peak non-repetitive forward surge current up to 50 A.
Compact SOD-128 plastic package with dimensions 4 mm length, 2.7 mm width and 1.1 mm height.
AEC-Q101 automotive qualified for demanding applications.

Product Description

Nexperia PMEG4030ETP,115 Schottky Diode is a surface mount type diode encapsulated in a small, flat 2-pin SOD-128 plastic package with dimensions approximately 4 mm by 2.7 mm by 1.1 mm. It is designed for medium power applications requiring high efficiency and low forward voltage drop.

Featuring a maximum continuous forward current of 3 A and a peak reverse repetitive voltage rating of 40 V, this Schottky diode provides reliable rectification performance with minimal power loss. It supports a peak non-repetitive forward surge current of up to 50 A, allowing transient current handling capabilities.

The device excels in applications where battery life extension and power efficiency are critical. It incorporates clip-bonding technology for enhanced power capability and is automotive grade AEC-Q101 qualified, enabling usage in automotive and industrial electronic systems.

Its key parameters include a low maximum forward voltage of 490 mV at rated current, peak reverse current of 23 mA, and ability to operate in temperature ranges from -55°C up to 175°C. This makes it suitable for a wide range of environments and industrial conditions.

Common applications include power management circuits, battery operated devices, power rectifiers in automotive systems, industrial control electronics, and other low voltage, high efficiency semiconductor circuits.

Operates at maximum continuous forward current of 3 A enabling medium power handling. Low forward voltage drop of 490 mV reduces conduction losses and increases efficiency. Compact SOD-128 package allows space-saving PCB layouts.

High operating temperature rating up to 175°C ensures stable performance in harsh conditions. AEC-Q101 qualification confirms automotive reliability and quality standards. Peak surge current up to 50 A supports transient load handling capability.

Ideal for automotive, industrial, and general electronics requiring Schottky barrier rectifiers.

Set your design apart with Nexperia’s PMEG4030ETP,115 diode offering reliability, efficiency, and compactness for cutting-edge semiconductor applications. Explore more semiconductors and Schottky diode solutions on EnvMart.
