Nexperia Medium Power Schottky Diode 60 V 2.83 A Forward Current Surface Mount SOD-123W PMEG6020AELRX

Free Delivery in India | Lowest Global Shipping Charges

Nexperia Medium Power Schottky Diode 60 V 2.83 A Forward Current Surface Mount SOD-123W PMEG6020AELRX

Name: Nexperia Medium Power Schottky Diode 60 V 2.83 A Forward Current Surface Mount SOD-123W PMEG6020AELRX
Brand: Nexperia
SKU: 398248
Price: 0.19 USD
Availability: InStock



Category Schottky Diodes & Rectifiers Brand Nexperia Condition New

Specifications

Country of Origin	India
Brand	Nexperia
Height	1.1mm
Length	2.8mm
Model	PMEG6020AELRX
Width	1.9mm
Mount Type	Surface
Series	PMEG6020AELP
Maximum Operating Temperature	175°C
Package Type	SOD-123W
Minimum Operating Temperature	-55°C
Pin Count	2
Automotive Standard	AEC-Q101
Maximum Continuous Forward Current If	2.83A
Peak Reverse Repetitive Voltage Vrrm	60V
Diode Configuration	Single
Rectifier Type	Schottky
Peak Reverse Current Ir	1.4mA
Peak Non-Repetitive Forward Surge Current Ifsm	50A
Maximum Forward Voltage Vf	670mV
Peak Reverse Recovery Time trr	9ns
Average forward current	IF(AV) ≤ 2 A
Reverse voltage	VR ≤ 60 V

Key Features

This Schottky diode features a low forward voltage of 670 mV for improved efficiency.
Operates at temperatures ranging from -55°C to 175°C, supporting demanding environments.
Equipped with an integrated guard ring for enhanced stress protection.
Complies with the AEC-Q101 automotive standard, ensuring high reliability and quality.
Compact surface mount device in a SOD-123W plastic package suitable for space-constrained designs.
Offers a peak non-repetitive forward surge current of 50 A for transient load handling.
Low reverse leakage current of 235 nA contributes to energy efficiency.
Designed for medium power applications requiring robust diode performance.

Product Description

Nexperia PMEG6020AELRX is a medium power Schottky diode designed for high efficiency and reliability in power management applications. Featuring a maximum continuous forward current of 2.83 A and a peak reverse repetitive voltage rating of 60 V, this diode is optimized for low forward voltage drop of 670 mV, reducing power losses in circuits.

The device is housed in a compact 2-pin SOD-123W surface-mounted plastic package, offering a small and flat profile ideal for space-saving PCB layouts. This Schottky diode is automotive qualified to AEC-Q101 standards, underscoring its suitability for automotive and industrial environments.

Its integrated guard ring provides stress protection, enhancing device robustness and endurance. With an operating temperature range from -55°C to 175°C and a peak non-repetitive forward surge current capability of 50 A, it supports demanding electrical conditions and transient surges.

Low forward voltage drop of 670 mV minimizes power dissipation. Reverse voltage rating up to 60 V for safe operation. Automotive standard AEC-Q101 qualification ensures reliability. Small form factor SOD-123W package supports compact designs.

Low leakage current reduces standby power consumption. High surge current tolerance supports transient events. Suitable for power management, battery protection, and switching applications.

This diode is ideal for industrial, automotive, power electronics, and electronic component manufacturing sectors seeking efficient Schottky rectifiers with robust performance and compliance to automotive standards. It enables energy-efficient operation in DC-DC converters, battery charging circuits, and power supplies requiring fast switching and low losses.
