Nexperia Schottky Barrier Diode 40 V 200 mA Surface Mount I-IGIA Package 1PS79SB30,115

Free Delivery in India | Lowest Global Shipping Charges

Nexperia Schottky Barrier Diode 40 V 200 mA Surface Mount I-IGIA Package 1PS79SB30,115

Name: Nexperia Schottky Barrier Diode 40 V 200 mA Surface Mount I-IGIA Package 1PS79SB30,115
Brand: Nexperia
SKU: 396511
Price: 0.07 USD
Availability: InStock



Category Schottky Diodes & Rectifiers Brand Nexperia Condition New

Specifications

Country of Origin	China
Brand	Nexperia
Height	0.65mm
Length	1.25mm
Model	1PS79SB30,115
Width	0.85mm
Mount Type	Surface
Series	1PS79SB30
Maximum Operating Temperature	150°C
Package Type	I-IGIA
Minimum Operating Temperature	-65°C
Pin Count	2
Automotive Standard	AEC-Q101
Maximum Continuous Forward Current If	200mA
Peak Reverse Repetitive Voltage Vrrm	40V
Diode Configuration	Single
Rectifier Type	Schottky
Peak Reverse Current Ir	500nA
Peak Non-Repetitive Forward Surge Current Ifsm	1A
Maximum Forward Voltage Vf	320mV
onsemi 40 V 250 mA Diode Schottky 2-Pin SOD-523 NSR0340V2T1GBrand	onsemi

Key Features

Features surface mount I-IGIA package with ultra-small low-profile design.
Maximum continuous forward current of 200 mA and peak repetitive reverse voltage of 40 V.
Low forward voltage drop of 320 mV for efficient energy use.
Operating temperature range from -65°C to 150°C for high reliability.
Low capacitance and negligible power switching losses suitable for fast switching.
Peak non-repetitive forward surge current up to 1 A enhances durability.
Automotive standard AEC-Q101 compliant ideal for automotive and industrial applications.

Product Description

Nexperia 1PS79SB30,115 is a high-efficiency Schottky Barrier Diode designed for surface-mounting on PCBs. It supports a maximum forward current of 200 mA and a peak reverse voltage of 40 V, making it suitable for power rectification and fast switching applications in electronics and automotive industries.

This diode features an ultra-compact I-IGIA package delivering low forward voltage drop of 320 mV, reducing power loss and improving thermal performance. It operates reliably within temperatures ranging from -65°C up to 150°C, meeting automotive-grade standards with AEC-Q101 certification.

The device is optimized for applications needing low leakage current and low capacitance, which enhances switching speed and reduces distortion in signal processing circuits. Its peak non-repetitive forward surge current of 1 A provides excellent transient handling capacity.

Physical dimensions are minimal, measuring 1.25 mm in length, 0.85 mm in width, and 0.65 mm in height, allowing for dense PCB layouts and compact electronic assemblies. Surface mount I-IGIA package ensures reliable soldering and automated assembly.

Maximum continuous forward current rating of 200 mA. Peak reverse repetitive voltage of 40 V limits reverse leakage. Low forward voltage drop of 320 mV for efficient conduction. Operating temperature range -65°C to 150°C ensures durability.

Compliant with automotive AEC-Q101 standard for quality assurance. Peak surge current rating up to 1 A protects against transient spikes. Dimensions: 1.25 mm length × 0.85 mm width × 0.65 mm height.

This Schottky diode is ideal for use in industrial electronics, automotive circuits, power supplies, and signal rectification tasks. It is designed for maximum efficiency and long-term stability in various demanding environments.
