onsemi Schottky Diode 50 V 3 A Surface Mount DO-214AB Package SS35
Specifications
| Country of Origin | India |
|---|---|
| Brand | onsemi |
| Height | 2.75mm |
| Length | 7.15mm |
| Model | SS35 |
| Width | 6.25mm |
| Mount Type | Surface |
| Series | SS35 |
| Maximum Operating Temperature | 150°C |
| Package Type | DO-214AB (SMC) |
| Minimum Operating Temperature | -55°C |
| Pin Count | 2 |
| Maximum Continuous Forward Current If | 3A |
| Peak Reverse Repetitive Voltage Vrrm | 50V |
| Diode Configuration | Single |
| Rectifier Type | Schottky |
| Peak Reverse Current Ir | 10mA |
| Peak Non-Repetitive Forward Surge Current Ifsm | 100A |
| Maximum Forward Voltage Vf | 750mV |
Key Features
- Features a DO-214AB (SMC) package type ensuring reliable surface mount capability.
- Provides low forward voltage drop with a maximum forward voltage of 750mV for efficient power applications.
- Supports high surge current of up to 100A peak non-repetitive forward surge current.
- Operates in a wide temperature range from -55°C to 150°C for versatile industrial use.
- Compact dimensions of 7.15mm length, 6.25mm width, and 2.75mm height facilitate space-saving circuit design.
- Designed as a single diode configuration with 2 pins optimized for power rectification.
- Peak reverse current is limited to 10mA to enhance device reliability.
- Ideal for power supply, protection, and rectification roles in electronic circuits.
Product Description
onsemi SS35 is a Schottky barrier rectifier diode designed for surface mount applications with a DO-214AB (SMC) package. It supports a maximum continuous forward current of 3A and can withstand a peak reverse voltage of 50V, suitable for various power electronics uses.
This diode features a low maximum forward voltage of 750mV, which allows efficient conduction and reduced power loss, beneficial in power supply and switching applications. It can handle a high peak non-repetitive forward surge current of up to 100A, providing robust surges protection.
With operating temperature range from -55°C to 150°C, it performs reliably in harsh environments, making it suitable for industrial electronics, automotive electronics, and consumer appliances.
The compact dimensions (7.15mm x 6.25mm x 2.75mm) enable designers to optimize circuit board space in densely packed electronic assemblies. Its single diode configuration with 2 pins and peak reverse current limited to 10mA enhance its performance and reliability.
onsemi manufactures this diode to stringent quality standards with no specific automotive certification but with proven reliability in multiple sectors. Surface mount DO-214AB (SMC) package type for easy PCB assembly. Maximum continuous forward current of 3A and peak reverse voltage of 50V.
Maximum forward voltage drop of 750mV ensures efficiency. High peak non-repetitive forward surge current; 100A rating. Wide operating temperature range from -55°C to 150°C. Compact size suitable for space-constrained applications.
Single diode, 2-pin configuration for standard circuit requirements. Peak reverse current limited to 10mA reduces leakage.
This Schottky diode is commonly used in industrial, consumer electronics, power management, and other electronic device applications where efficient low forward voltage drop and diode robustness are critical. It is ideal for rectification, freewheeling, and voltage clamping circuits.
Explore more Schottky Diodes and rectifiers on EnvMart for diverse application needs and trusted industrial-grade semiconductor components.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum continuous forward current of this Schottky diode is 3A.
The peak reverse voltage rating for the SS35 diode is 50V.
The maximum forward voltage drop for this model is 750mV.
The dimensions of the diode are 7.15mm in length, 6.25mm in width, and 2.75mm in height.
The peak non-repetitive forward surge current rating is 100A.
The operating temperature range for this diode is from -55°C to 150°C.
The SS35 diode uses a DO-214AB (SMC) package type.
This diode has 2 pins.
The peak reverse current for this diode is limited to 10mA.
The SS35 is a Schottky rectifier.
This diode is commonly used in industrial, consumer electronics, power management, and other electronic device applications.
The configuration of this diode is single.
