onsemi Schottky Barrier Rectifier Diode 80 V 3 A Surface Mount DO-214AB Package SS38

onsemi SS38 is a Schottky Barrier Rectifier Diode specifically designed for power and switching applications requiring low forward voltage drop and fast switching speed. It is housed in a surface mount DO-214AB (SMC) package that facilitates compact and efficient circuit designs.

This diode supports a peak repetitive reverse voltage (Vrrm) of 80 V and a maximum continuous forward current (If) of 3 A. It offers a peak non-repetitive forward surge current (Ifsm) of 100 A, making it suitable for handling transient current loads effectively.

The device exhibits a maximum forward voltage (Vf) of 850 mV and a peak reverse current (Ir) of 10 mA, ensuring efficient rectification and minimal leakage under normal operating conditions. Operating temperature range is from -55°C minimum to 150°C maximum, allowing use in a broad spectrum of industrial and commercial environments.

Mechanical dimensions of the diode are precise, with a length of 7.15 mm, width of 6.25 mm, and height of 2.75 mm, supporting automated surface mount technology assembly.

This diode is well-suited for industrial, electronic, power supply, and general semiconductor use cases where efficient rectification and reliable operation under various environmental conditions are required.

This Schottky Diode features a maximum forward voltage of 850 mV. It supports a peak non-repetitive forward surge current of 100 A. The device operates reliably from -55°C to 150°C ambient temperature range. The compact package dimensions are 7.15 mm length, 6.25 mm width, and 2.75 mm height.

Its 2-pin design enables efficient surface mount assembly for power rectification applications. Explore more semiconductor and diode components at EnvMart to enhance your electronic designs with trusted onsemi products.
