TDK Shielded Wirewound Surface Mount Inductor with Ferrite Core 220 μH ±20 % 1.16 A Idc B82477G4224M000

TDK B82477G4224M000 is a high-quality shielded wirewound surface mount inductor constructed with a ferrite core and enamel copper wire winding. It offers an inductance of 220 μH with a tolerance of ±20 % and supports a maximum DC current of 1.16 A, making it ideal for precise filtering and power supply stabilization in electronic circuits.

The inductor features a compact design with dimensions of 12.8 mm length, 8 mm height, and 12.8 mm depth, fitting efficiently into densely packed printed circuit boards. Its solder termination style ensures reliable electrical and mechanical connections for surface mount technology applications.

Designed for robust operation, it functions reliably over a temperature range from -55°C to 125°C and has a maximum DC resistance of 380 mΩ, ensuring efficiency and stable performance in demanding environments.

This series includes magnetically shielded inductors suitable for applications such as filtering of supply voltages, DC-DC converters, and automotive electronics. The B82477-G4 series supports adherence to RoHS directives, ensuring environmental safety of the component.

Features ferrite core shielding to minimize electromagnetic interference. Wirewound construction provides stable inductance characteristics. Packaged in tape and reel formats for automated manufacturing processes. Suitable for industrial, automotive, power electronics, and general electronics use cases.

Ensures durability and soldering reliability with lead-free tinned terminals.

This TDK B82477G4224M000 surface mount inductor is well-suited for precise and reliable inductance requirements in power and signal conditioning applications, making it a valuable component for electronics manufacturing and repair.
