TDK Shielded Wirewound Surface Mount Inductor with Ferrite Core 2.2 μH ±30 % 3.25 A Idc VLCF5020T-2R2N2R6-3
Specifications
| Country of Origin | India |
|---|---|
| Brand | TDK |
| Height | 2mm |
| Length | 5mm |
| Model | VLCF5020T-2R2N2R6-3 |
| Depth | 5mm |
| Packaging | Tape & Reel |
| Series | VLCF |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -40°C |
| Core Material | Ferrite |
| Inductance | 2.2μH |
| Standards/Approvals | RoHS |
| Package/Case | 5020 |
| Maximum DC Current | 3.25A |
| Pin Count | 2 |
| Maximum DC Resistance | 43mΩ |
| Inductance Tolerance | ±30 % |
| Termination Style | Solder |
| Inductor Construction | Shielded |
Key Features
- This inductor uses a shielded construction ensuring reduced electromagnetic interference.
- Designed with a ferrite core to provide high magnetic shielding effectiveness.
- Suitable for power circuits and portable DC to DC converter applications.
- Compact package size 5020 with dimensions of 5mm length, 2mm height, and 5mm depth.
- Maximum operating temperature is 105°C ensuring reliable operation in harsh environments.
- Termination style is solder, compatible with automated surface mount assembly technologies.
- Meets RoHS standards complying with environmental and safety regulations.
- Packaging is tape and reel for efficient automated placement during production.
Product Description
TDK VLCF5020T-2R2N2R6-3 shielded wirewound surface mount inductor with ferrite core offers an inductance of 2.2 μH with ±30 % tolerance and a maximum DC current rating of 3.25 A. It is constructed using a high magnetic shield technology designed for portable DC to DC converter line power circuits, ensuring reduced electromagnetic interference and improved performance.
This professional series VLCF inductor features a compact 5020 package with dimensions 5 mm length, 2 mm height, and 5 mm depth, optimized for surface mounting on PCBs. The inductor's ferrite core and shielded construction provide effective magnetic shielding suitable for mobile devices such as HDDs, digital video cameras, digital still cameras, and LCD displays.
The device supports solder termination style and comes packaged in tape and reel format, allowing high-efficiency automated assembly in manufacturing. It operates within a temperature range from -40°C to 105°C, making it reliable for industrial and electronic applications requiring durability and thermal stability.
Designed to meet RoHS compliance standards, this inductor guarantees environmentally friendly manufacturing. It is ideal for use in power source inductors of DC to DC converters and portable device power circuits in industrial, commercial electronics, and consumer electronics sectors.
This inductor uses a shielded construction ensuring reduced electromagnetic interference. Designed with a ferrite core to provide high magnetic shielding effectiveness. Suitable for power circuits and portable DC to DC converter applications.
Compact package size 5020 with dimensions of 5mm length, 2mm height, and 5mm depth. Maximum operating temperature is 105°C ensuring reliable operation in harsh environments. Termination style is solder, compatible with automated surface mount assembly technologies.
Meets RoHS standards complying with environmental and safety regulations. Packaging is tape and reel for efficient automated placement during production. Explore other Surface Mount Inductors and related electronic components at EnvMart for your electronic and industrial needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The inductance value of this inductor is 2.2 μH with a tolerance of ±30%.
The maximum DC current rating for the TDK VLCF5020T-2R2N2R6-3 is 3.25 A.
The dimensions of the 5020 package are 5 mm in length, 2 mm in height, and 5 mm in depth.
The maximum operating temperature for this model is 105°C.
It uses a solder termination style, making it compatible with automated surface mount assembly technologies.
This inductor features a ferrite core and a shielded construction for effective magnetic shielding.
The TDK VLCF5020T-2R2N2R6-3 complies with RoHS standards, ensuring environmentally friendly manufacturing.
The minimum operating temperature is -40°C, allowing reliable performance in low-temperature environments.
It is packaged in tape and reel format, which facilitates efficient automated placement during production.
This inductor is suitable for power circuits and portable DC to DC converter applications.
The maximum DC resistance is 43 mΩ, which contributes to its efficiency in power applications.
This model has a pin count of 2.
