TDK Chassis Mount EMC Filter 8A 250V ac/dc 50Hz 60Hz Tab 1 Phase B84112G0000B080

Free Delivery in India | Lowest Global Shipping Charges

TDK Chassis Mount EMC Filter 8A 250V ac/dc 50Hz 60Hz Tab 1 Phase B84112G0000B080



Category EMC Filter Brand TDK Condition New

Specifications

Country of Origin	China
Brand	TDK
Height	29mm
Length	84.7mm
Model	B84112G0000B080
Depth	52mm
Mount Type	Chassis Mount
Operating Frequency	50, 60Hz
Series	B84112G
Maximum Operating Temperature	100°C
Number Of Stages	1
Capacitance	2pF
Minimum Operating Temperature	-25°C
Maximum Current	8A
Number of Phases	1
Leakage Current	369μA
Maximum Voltage	250V ac/dc
Inductance	5mH
Standards/Approvals	UL1283
Termination Style	Tab

Key Features

The filter supports operation at 50Hz and 60Hz frequencies.
Compact chassis mount design with tab termination style allows easy installation.
Features one stage with 2pF capacitance and 5mH inductance for effective EMI filtering.
Operates safely from -25°C to 100°C ambient temperatures.
Leakage current is low at 369μA ensuring energy efficiency.
Constructed with a metal case suitable for harsh industrial environments.
Compliance with UL1283 standard ensures quality and safety.
Applications include industrial electronics, switch-mode power supplies, telecom and data systems.

Product Description

TDK B84112G0000B080 chassis mount EMC filter is designed for suppression of electromagnetic interference on single phase power lines. Rated for a maximum current of 8A and voltage of 250V ac or dc, it operates efficiently at frequencies of 50Hz and 60Hz. Its compact and robust metal construction allows easy mounting on chassis with tab termination style ensuring secure electrical connections.

The filter consists of one stage containing 2pF capacitance and 5mH inductance delivering excellent attenuation characteristics for noise reduction in industrial electronics and power supplies. Its leakage current is controlled to a low 369μA, minimizing power loss and enhancing energy efficiency.

Operating temperature range from -25°C to 100°C allows deployment in diverse environments including industrial machinery, telecom systems, data communication equipment, and some medical devices (specific versions). The unit meets UL1283 standard for electromagnetic compatibility filter components.

This power line filter provides reliable protection for sensitive electronic equipment against conducted interference and helps maintain system stability and compliance with electromagnetic compatibility regulations. It is part of TDK's B84112G series tailored for high-performance EMI filtering in industrial applications.

The filter supports operation at 50Hz and 60Hz frequencies. Compact chassis mount design with tab termination style allows easy installation. Features one stage with 2pF capacitance and 5mH inductance for effective EMI filtering.

Operates safely from -25°C to 100°C ambient temperatures. Leakage current is low at 369μA ensuring energy efficiency. Constructed with a metal case suitable for harsh industrial environments. Compliance with UL1283 standard ensures quality and safety.

Applications include industrial electronics, switch-mode power supplies, telecom and data systems. Manufactured in China and designed for long-term reliable performance. Series designation is B84112G, making it suitable for various power line filter requirements.
