Wurth Elektronik Polypropylene Capacitor X2, 100nF 630V dc 310V ac, Through Hole Mount 10mm Pitch 890334023023CS

Free Delivery in India | Lowest Global Shipping Charges

Wurth Elektronik Polypropylene Capacitor X2, 100nF 630V dc 310V ac, Through Hole Mount 10mm Pitch 890334023023CS

Name: Wurth Elektronik Polypropylene Capacitor X2, 100nF 630V dc 310V ac, Through Hole Mount 10mm Pitch 890334023023CS
Brand: Wurth Elektronik
SKU: 383133
Price: 0.4 USD
Availability: InStock



Category Capacitors Brand Wurth Elektronik Condition New

Specifications

Country of Origin	India
Brand	Wurth Elektronik
Operating Temperature	-40 °C to +105°C
Height	13mm
Length	13mm
Model	890334023023CS
Packaging	5000
Width	7mm
Mount Type	Through Hole
Series	WCAP-FTXX
Maximum Operating Temperature	105°C
Tolerance	±10 %
Capacitance	100nF
Minimum Operating Temperature	-40°C
Terminal type	Through Hole
Dissipation Factor	0.5%
Lead Length	4mm
Standards/Approvals	VDE, ENEC, cULus, CQC
Package/Case	5000
Rated AC Voltage	310V ac
Rated DC Voltage	630V dc
Lead Pitch	10mm
Lead Diameter	0.6mm
Applications include	Safety applications, Filter and Power Supplies
Suppression Class	X2

Key Features

The capacitor is rated for 630 V dc and 310 V ac voltage operation.
It has an operating temperature range of -40°C to 105°C, ensuring reliable performance under diverse environmental conditions.
Constructed with metallized polypropylene film, it features self-healing properties and encapsulated in UL94V-0 compliant material for safety.
Designed for EMI filter, interference suppression coil, and safety applications in electronic circuits.
Lead length measures 4mm with a diameter of 0.6mm; physical dimensions are 13mm height, 13mm length, and 7mm width.
Compliant with standards including VDE, ENEC, cULus, and CQC certifications.
Provided in packaging of 5000 pieces for efficient production usage.

Product Description

Wurth Elektronik 890334023023CS Polypropylene Capacitor X2 is a high-quality MKP metallized film capacitor designed for EMI filters, interference suppression coils, and safety-critical applications.

This capacitor offers a capacitance of 100nF with a tolerance of ±10 %, supporting operating voltages of up to 630 V dc and 310 V ac. It features through hole mounting with a 10mm lead pitch and leads measuring 4mm in length and 0.6mm in diameter, facilitating secure installation on PCBs.

The capacitor operates reliably within a temperature range of -40°C to 105°C and is encapsulated in a self-extinguishing UL94V-0 rated material, providing enhanced fire safety. Physical dimensions measure 13mm in height and length, with a 7mm width, suitable for various compact circuit designs.

The product complies with international standards including VDE, ENEC, cULus, and CQC, ensuring quality and reliability for industrial and commercial electronic equipment. This product is supplied in bulk packaging of 5000 units, supporting large-scale manufacturing and assembly operations.

The capacitor's self-healing metallized polypropylene film extends longevity and performance stability. Designed specifically for safety applications and filters requiring X2 suppression class certification. Recommended for wave soldering processes in PCB assembly to ensure secure mounting.

Applications include power supplies, electronic filtering circuits, and EMI noise suppression. Its radial leaded form factor is optimized for through hole PCB assembly techniques.
