Broadcom 2-Channel Optocoupler Through Hole 8-Pin DIP HCPL-2232-000E

Free Delivery in India | Lowest Global Shipping Charges

Broadcom 2-Channel Optocoupler Through Hole 8-Pin DIP HCPL-2232-000E

Name: Broadcom 2-Channel Optocoupler Through Hole 8-Pin DIP HCPL-2232-000E
Brand: Broadcom
SKU: 380570
Price: 9.93 USD
Availability: InStock



Category Optocoupler Brand Broadcom Condition New

Specifications

Country of Origin	India
Brand	Broadcom
Model	HCPL-2232-000E
Mount Type	Through Hole
Series	HCPL
Maximum Operating Temperature	85°C
Package Type	DIP
Minimum Operating Temperature	-40°C
Maximum input current	230mA
Number Of Channels	2
Standards/Approvals	UL 1577, IEC/EN/DIN EN 60747-5-2, CSA
Maximum Forward Voltage	1.85V
Number of Pins	8
Typical Rise Time	30ns
Typical Fall Time	7ns

Key Features

This optocoupler features two channels for reliable signal isolation.
It supports a maximum forward voltage of 1.85 volts.
The package type is DIP with through hole mounting suitable for PCB insertion.
Typical rise and fall times are 30ns and 7ns respectively, enabling fast switching.
Maximum input current is 230mA for robust operation.
Designed for operation in temperature range from -40°C to 85°C.
It complies with international standards including UL 1577, IEC/EN/DIN EN 60747-5-2 and CSA.
The product offers electrical isolation with 3750 Vrms isolation voltage.

Product Description

Broadcom HCPL-2232-000E is a high quality 2-channel optocoupler designed with an 8-pin Dual Inline Package (DIP) and through-hole mount. It provides reliable electrical isolation between input and output circuits to protect sensitive components from high voltages and transients.

This optocoupler supports a maximum forward voltage of 1.85 volts and a maximum input current of 230mA, making it suitable for a wide range of industrial and commercial electronic applications. The device operates efficiently over a temperature range from -40°C to 85°C, ensuring consistent performance in varying environmental conditions.

The typical rise time is 30 nanoseconds and fall time is 7 nanoseconds, supporting fast switching speeds required in modern electronic circuits. It meets stringent international safety and performance standards such as UL 1577, IEC/EN/DIN EN 60747-5-2, and CSA, guaranteeing compliance and reliability.

The product’s logical output interface makes it ideal for interfacing with microcontrollers, digital systems, and other control electronics requiring isolation to prevent electrical noise and damage.

This optocoupler is commonly used in industrial automation, instrumentation, power supply systems, telecommunications, and other fields where signal isolation and noise immunity are critical for system stability.

This Optocoupler features two channels for reliable signal isolation. It supports a maximum forward voltage of 1.85 volts. The package type is DIP with through hole mounting suitable for PCB insertion. Typical rise and fall times are 30ns and 7ns respectively, enabling fast switching.

Maximum input current is 230mA for robust operation. Designed for operation in temperature range from -40°C to 85°C. It complies with international standards including UL 1577, IEC/EN/DIN EN 60747-5-2 and CSA. The product offers electrical isolation with 3750 Vrms isolation voltage.

Logic output type ensures compatibility with digital circuits. Ideal for use in industrial and electronic control systems requiring electrical isolation. Explore more related components and electronic parts on EnvMart to find high quality industrial electronics suitable for your projects and applications.
