Wurth Elektronik 361 Series Pluggable Terminal Block, 4-Contact, 3.81 mm Pitch, 1 Row, 300V AC, 10.5A Current 691361300004

Wurth Elektronik 691361300004 is a high-quality 361 Series pluggable terminal block designed for electronic and electrical power connector applications. This pluggable terminal block features 4 contacts arranged in a single row with a 3.81 mm pitch, suitable for vertical cable mount configurations. Operating at 300V AC and rated for a continuous current of 10.5 Amperes, it provides safe and reliable electrical connections for industrial and commercial assemblies.

The terminal block utilizes a green polyamide (PA66) housing with a UL94-V0 flame retardant rating, ensuring excellent mechanical strength and fire safety. Its male connector design and straight orientation facilitate easy integration onto printed circuit boards (PCBs). Wire connection is accomplished via cable entry using a slot-type M2 screw terminal, supporting wire sizes from 26 AWG to 16 AWG (0.13 mm² to 1.31 mm²), making it versatile for various wiring applications.

With compact physical dimensions of 15.24 mm length, 15.8 mm width, and 11.1 mm depth, this terminal block is suitable for installations requiring space-efficient connectors. The tin-plated phosphor bronze contacts enhance corrosion resistance and ensure long-term electrical conductivity. Manufactured in China under strict quality controls, the 361 Series maintains the high standards associated with Wurth Elektronik products.

This Pluggable Terminal Block finds wide usage in industrial automation, electronic instrumentation, power supply units, HVAC controls, and other electrical systems requiring secure detachable connections. It supports quick assembly and maintenance by enabling easy plug-and-play terminal replacement.

Features 4 contacts with a pitch of 3.81 mm for precise cable connection. Supports a maximum current of 10.5 Amperes for reliable power transmission. Compatible with wire sizes from 26 to 16 AWG and 0.13 to 1.31 mm². Constructed from green polyamide housing material with UL94-V0 flame rating for safety.

Male connector gender with straight orientation for easy PCB mounting. Compact dimensions: length 15.24 mm, width 15.8 mm, depth 11.1 mm, ideal for space-constrained assemblies. Wire connection by cable entry method with tin-plated phosphor bronze contacts for corrosion resistance.

Product is manufactured in China maintaining industrial quality standards. Explore more Wurth Elektronik products in the Electronics Components category at EnvMart to find suitable connectors and accessories for your projects.
