Weidmüller BL Series Pluggable Terminal Block 12-Contact 3.5 mm Pitch 1 Row 320V 17A 1606740000
Specifications
| Country of Origin | Germany |
|---|---|
| Voltage | 320V |
| Brand | Weidmüller |
| Colour | Orange |
| Current | 17A |
| Depth | 18.5mm |
| Width | 13mm |
| Housing Material | Polybutylene Terephthalate |
| Series | BL |
| Number of Rows | 1 |
| Pitch | 3.5mm |
| Number of Contacts | 12 |
| Connector Gender | Male |
| Minimum Wire Size mm² | 0.08mm² |
| Maximum Wire Size mm² | 2.5mm² |
| Minimum Wire Size AWG | 28AWG |
| Maximum Wire Size AWG | 14AWG |
| Wire Connection Method | Screw |
Key Features
- Features 12 contacts with a 3.5 mm pitch suitable for compact installations.
- Single row configuration optimizes space while maintaining connectivity.
- Constructed from durable Polybutylene Terephthalate housing for enhanced insulation.
- Supports wire sizes from 0.08 mm² to 2.5 mm² with screw connection method.
- Male connector gender with orange color for easy identification.
- Compact width of 13 mm and depth of 18.5 mm for versatile mounting options.
- Clamping yoke screw system enables easy and secure wiring.
- Tin plated copper alloy terminals ensure excellent conductivity and corrosion resistance.
Product Description
Weidmüller 1606740000 BL Series Pluggable Terminal Block features 12 contacts arranged in a single row with a 3.5 mm pitch suitable for a variety of electronic and electrical applications. Rated for 320V and 17A, this terminal block offers a reliable connection solution with its screw connection method and robust housing made from Polybutylene Terephthalate. The male connector gender and orange color coding simplify identification during installation and maintenance.
Designed with a clamping yoke screw system, this terminal block ensures fast and secure wire connections with support for wire sizes ranging from 0.08 mm² to 2.5 mm². The housing offers compact dimensions with a 13 mm width and 18.5 mm depth, making it suitable for dense PCB layouts or industrial control panels.
The terminals are made from tin plated copper alloy for enhanced conductivity and corrosion resistance. The product meets UL94 V-0 flammability classification, supporting safety compliance in demanding industrial environments.
This Pluggable Terminal Block is ideal for use in industrial, manufacturing, automation, and electronics applications where reliable wire connections and compact form factors are required. It supports easy wiring, maintenance, and replacement, reducing downtime and improving operational efficiency.
Features 12 contacts with 3.5 mm pitch for compact PCB mounting. Robust Polybutylene Terephthalate housing offers superior insulation. Supports a wire range from 0.08 mm² to 2.5 mm² using screw termination. Rated current of 17A and voltage rating of 320V for reliable power handling.
Male connector gender and orange coloring for operator convenience. Compact dimensions: width 13 mm and depth 18.5 mm. Clamping yoke screw system allows easy and secure connection. Conductive parts are tin plated copper alloy ensuring performance and corrosion resistance.
Complies with UL94 V-0 flammability standards. Suitable for industrial, automation, electronics manufacturing, and commercial controls. Weidmüller products offer high quality and reliability. Explore more terminal blocks and connectivity solutions at EnvMart for your industrial and electronic component needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This terminal block is rated for a voltage of 320V and a current of 17A.
It features a 3.5 mm pitch with 12 contacts arranged in a single row.
This terminal block supports wire sizes ranging from 0.08 mm² to 2.5 mm².
The housing is constructed from Polybutylene Terephthalate, providing enhanced insulation.
The compact dimensions are 13 mm in width and 18.5 mm in depth.
Wiring is connected using a screw connection method, ensuring secure and easy installation.
It has a male connector gender, which is color-coded in orange for easy identification.
Yes, it complies with the UL94 V-0 flammability classification, supporting safety in industrial environments.
It is suitable for industrial, automation, electronics manufacturing, and commercial control applications.
It utilizes a clamping yoke screw system for fast and secure wire connections.
The country of origin for this terminal block is Germany.
The minimum wire size is 28 AWG and the maximum wire size is 14 AWG.
