Seeed Studio Arduino Compatible CAN-BUS Shield Module with MCP2515 Controller and MCP2551 Transceiver V2 103030215

Seeed Studio 103030215 CAN-BUS Shield V2 is an advanced Arduino compatible shield designed for enabling Controller Area Network (CAN) communication based on CAN V2.0B standard at speeds up to 1 Mb/s. It integrates the MCP2515 CAN controller and the MCP2551 CAN transceiver for efficient and reliable CAN bus communication.

The module includes a micro-SD card reader operating via SPI protocol, allowing local data storage for logging purposes. It is equipped with an industrial standard 9 pin sub-D connector and features selectable OBD-II and CAN standard pinouts making it suitable for automotive diagnostic and industrial applications. The shield supports Arduino Uno pin headers, as well as two Grove connectors offering I2C and UART interfaces for expanded connectivity and prototyping flexibility.

The chip select (CS) pins for the CAN controller and TF card slot and the interrupt (INT) pins are changeable, enabling easy customization depending on user requirements. Screw terminals are included to securely connect CAN_H and CAN_L signal lines. The shield accommodates both standard 11-bit and extended 29-bit CAN data and remote frames, providing robust communication capability.

Applications include industrial monitoring systems, data-logging tools, embedded diagnostic instruments, and more, fitting well in manufacturing, automotive, industrial automation, and IoT development environments. The shield is a dependable solution for developers and engineers looking to integrate CAN bus functionality in Arduino-based projects.

The shield uses MCP2515 CAN controller and MCP2551 CAN transceiver for robust communication. Supports CAN communication speeds up to 1 Mb/s. Includes a micro-SD card reader interfaced via SPI bus for data logging. Industrial standard 9 pin sub-D connector and selectable OBD-II and CAN standard pinouts are provided.

Offers Arduino Uno pin headers and two Grove connectors for I2C and UART connectivity. Changeable chip select and interrupt pins enhance flexibility for integration. Screw terminals allow easy connection of CAN_H and CAN_L lines.

Supports standard (11-bit) and extended (29-bit) CAN data and remote frames. Equipped with two message receive buffers with prioritized message storage. Designed for applications such as industrial monitoring, embedded diagnostics, and data logging.

Country of origin is China. Product condition is New. This shield is an ideal choice for industrial, automotive, and embedded system applications requiring reliable CAN bus communication with Arduino compatibility. Browse the Electronics & Electricals category at EnvMart for more Electronic Components and development tools.
