Weidmüller OMNIMATE SC Series Pluggable Terminal Block 3-Contact 3.81 mm Pitch 1 Row Male Connector 320V 17.5A 1864080000
Specifications
| Country of Origin | Germany |
|---|---|
| Voltage | 320V |
| Brand | Weidmüller |
| Colour | Black |
| Orientation | Straight |
| Current | 17.5A |
| Length | 1.5mm |
| Depth | 7.1mm |
| Width | 21.72mm |
| Housing Material | Glass Filled Liquid Crystal Polymer |
| Series | OMNIMATE SC |
| Number of Rows | 1 |
| Pitch | 3.81mm |
| Standards/Approvals | CSA, cURus |
| Pay online using | Or choose to pay later via bank transfer |
| RS Stock No. | 739-4315Brand: WeidmüllerManufacturers Part No.: 1864080000 |
| Number of Contacts | 3 |
| Connector Gender | Male |
| Wire Connection Method | Solder |
Key Features
- Constructed with glass-filled liquid crystal polymer housing for durability.
- Supports current rating of 17.5A at a voltage of 320V.
- Features 1.5 mm pin length suitable for Through Hole Reflow soldering.
- Designed with a male connector and straight orientation for easy installation.
- Complies with CSA and cURus safety standards.
- Ideal for industrial, manufacturing, HVAC, and laboratory electronic circuit applications.
Product Description
The Weidmüller OMNIMATE SC Series Pluggable Terminal Block 1864080000 offers a high-quality solution for electrical and electronic connection needs in industrial and laboratory environments. It is designed with 3 contacts arranged in a single row with a precise 3.81 mm pitch, supporting a nominal current of 17.5A and a voltage rating of 320V. The housing material is a robust glass-filled liquid crystal polymer, ensuring excellent mechanical strength and thermal resistance for demanding operating conditions.
This pluggable terminal block features a male connector with a straight orientation for secure and easy connectivity. The 1.5 mm pin length is optimized for Through Hole Reflow (THR) soldering processes and includes extra solder pins to enhance mechanical stability between the PCB and the header.
With compact dimensions including a width of 21.72 mm and a depth of 7.1 mm, it facilitates installation in tight PCB layouts. The product complies with recognized safety standards CSA and cURus, assuring reliable operation in different industrial and commercial applications.
Common use cases for the OMNIMATE SC series include electronic circuit assembly, control cabinets, automation systems, and power distribution modules within manufacturing and HVAC sectors. The terminal block’s durable build and precise specifications make it a dependable component for long-term industrial service.
Constructed with glass-filled liquid crystal polymer housing for durability. Supports current rating of 17.5A at a voltage of 320V. Features 1.5 mm pin length suitable for Through Hole Reflow soldering. Designed with a male connector and straight orientation for easy installation.
Complies with CSA and cURus safety standards. Compact dimensions: 21.72 mm width, 7.1 mm depth, and 1.5 mm pin length. Ideal for industrial, manufacturing, HVAC, and laboratory electronic circuit applications. Explore the full range of Pluggable Terminal Blocks at EnvMart for reliable and high-quality electronic components tailored for your technical needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model supports a current rating of 17.5A and a voltage rating of 320V.
It features a pitch of 3.81 mm and has 3 contacts arranged in a single row.
The housing is constructed from glass-filled liquid crystal polymer, providing mechanical strength and thermal resistance.
The pin length is 1.5 mm, which is suitable for Through Hole Reflow soldering processes.
It has a width of 21.72 mm and a depth of 7.1 mm, making it compact for tight PCB layouts.
It complies with CSA and cURus safety standards, ensuring reliable operation in various applications.
This model features a straight orientation for easy installation.
It is ideal for use in industrial, manufacturing, HVAC, and laboratory electronic circuit applications.
The wire connection method is solder, suitable for secure electrical connections.
The country of origin for this terminal block is Germany.
This terminal block is designed with a male connector.
This terminal block belongs to the OMNIMATE SC Series.
