Weidmüller BL Series Pluggable Terminal Block 16-Contact 3.5 mm Pitch 1 Row 1606780000
Specifications
| Country of Origin | Germany |
|---|---|
| Voltage | 320V |
| Brand | Weidmüller |
| Colour | Orange |
| Orientation | 180° |
| Current | 17A |
| Length | 52.5mm |
| Depth | 18.5mm |
| Width | 63mm |
| Housing Material | Polybutylene Terephthalate |
| Series | BL |
| Number of Rows | 1 |
| Pitch | 3.5mm |
| Number of Contacts | 16 |
| Connector Gender | Female |
| Minimum Wire Size mm² | 0.08mm² |
| Maximum Wire Size mm² | 1.5mm² |
| Minimum Wire Size AWG | 28AWG |
| Maximum Wire Size AWG | 14AWG |
| Wire Connection Method | Clamping Yoke |
Key Features
- Features a female plug with a clamping yoke screw system.
- Rated current of 17A supports wire sizes from 0.08mm² to 1.5mm².
- Compact 3.5 mm pitch enables space-saving and efficient wiring.
- Manufactured with durable Polybutylene Terephthalate housing providing electrical insulation.
- Wire connection via hardened zinc-chromed plated clamping yoke for reliable contact.
- Orientation supports 180° wire outlet direction to simplify installation.
- Orange color housing for clear identification in assemblies.
- Complies with UL94 V-0 flammability class for safety.
Product Description
Weidmüller 1606780000 is a high-quality pluggable terminal block from the BL Series designed for reliable electronic and electrical connections in industrial and manufacturing environments. This 16-contact terminal block features a 3.5 mm pitch and a single row configuration, optimizing PCB layout and wiring density.
The female plug incorporates a robust clamping yoke screw system, using hardened, zinc-chromed plated steel to ensure secure wire connections with minimal maintenance. Wires ranging from minimum 0.08 mm² (28 AWG) to maximum 1.5 mm² (14 AWG) can be accommodated, supporting rated currents up to 17 amperes.
The housing is made of Polybutylene Terephthalate, known for electrical insulation, mechanical strength, and resistance to heat and chemicals, suitable for demanding industrial applications. The block’s compact dimensions (52.5 mm length, 63 mm width, 18.5 mm depth) enable efficient space utilization on PCBs with vertical or horizontal mounting options.
Its 180° orientation wire outlet provides straightforward wiring access, reducing assembly complexity in control systems, automation equipment, and power electronics. The orange housing facilitates easy identification, beneficial in complex wiring harnesses.
Female plug with clamping yoke screw termination for secure connections. Rated current of 17A corresponding to rated cross-section and poles. Space-saving 3.5 mm pitch from the Weidmüller Omnimate range. Supports wire sizes from 0.08 mm² (28 AWG) up to 1.5 mm² (14 AWG).
Durable Polybutylene Terephthalate housing material for electrical safety. Dimensions suited for standard PCB mounting and integration. 180° wire outlet orientation for easy wiring direction. Complies with UL94 V-0 flammability standard for electrical components.
Manufactured in Germany ensuring premium quality control.
This terminal block is ideal for industrial automation systems, electrical distribution equipment, and manufacturing control panels requiring secure, reliable, and maintainable wire connections. For compatible headers, see stock numbers (180°) 762-6343 and (90°) 762-6303. Browse the Weidmüller BL Series and other Pluggable Terminal Blocks at EnvMart for comprehensive solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model has a rated current of 17A and can handle a voltage of up to 320V.
It accommodates wire sizes ranging from 0.08 mm² (28 AWG) to 1.5 mm² (14 AWG).
The terminal block has a length of 52.5 mm, a width of 63 mm, and a depth of 18.5 mm.
It features a compact 3.5 mm pitch, which allows for efficient wiring.
It uses a clamping yoke screw system for secure wire connections.
The housing is made of Polybutylene Terephthalate, providing electrical insulation and mechanical strength.
The wire outlet is oriented at 180°, simplifying installation and wiring access.
This model features 16 contacts in a single row configuration.
The housing is orange, which aids in clear identification during assembly.
It is manufactured in Germany, ensuring quality control.
It complies with the UL94 V-0 flammability class for safety in electrical components.
It is ideal for industrial automation systems, electrical distribution equipment, and manufacturing control panels.
