Weidmüller BL Series Pluggable Terminal Block 4-Contact 3.5 mm Pitch 1 Row 320V 12A 1639030000

Weidmüller 1639030000 BL Series pluggable terminal block is a high-quality electrical connector designed for secure and efficient wire termination in electronic and power connector applications. Featuring 4 contacts arranged in a single row with a 3.5 mm pitch, it enables precise and compact PCB mounting.

Constructed with robust polybutylene terephthalate housing and a hardened, zinc-chromed plated clamping yoke steel, this terminal block ensures mechanical strength and corrosion resistance. It supports wire sizes from 0.08 mm² (28 AWG) up to 2.5 mm² (14 AWG), accommodating a wide range of wiring needs. The screw connection method facilitates reliable and easy wiring.

The product is rated for a maximum current of 12A and can handle up to 320V, making it suitable for various industrial electronic, automation, and control system installations. Its compact dimensions of 22.45 mm width and 14.6 mm depth contribute to efficient use of PCB space. The terminal block is orange in color for quick identification and features a female plug with a 90° flanged mounting for secure cable attachment.

This pluggable terminal block belongs to the Weidmüller BL series within the Omnimate range, offering cost-effective, space-saving solutions for PCB applications, including vertical or horizontal headers. It is compatible with mating harness connectors utilizing tension clamp or rising clamp screw terminals and includes polarized pins to prevent mismatching during connections.

Weidmüller’s BL series terminal blocks are widely used in industrial automation, manufacturing control panels, power distribution, and electronic equipment requiring reliable and maintainable wiring solutions. No specific standards or approvals are declared for this product. For flanged header accessories, refer to stock numbers 762-6343 (180 °) and 762-6303 (90 °) as typical examples.

Constructed with polybutylene terephthalate housing for durability. Supports wire sizes from 0.08 mm² to 2.5 mm² or 28 AWG to 14 AWG. Rated current capacity of 12A ensuring stable electrical performance. Orange color coding aids in easy identification and wiring.

Screw connection method with hardened and zinc-chromed plated clamping yoke steel. Compact dimensions: 22.45 mm width and 14.6 mm depth for space-saving installation. Designed as female plug with a 90° flanged mounting for secure attachment.

Compatible with Weidmüller Omnimate range connectors for versatile use. No specific standards or approvals declared.

Explore the Weidmüller BL Series Pluggable Terminal Blocks at EnvMart for robust and efficient electronic and power connectors tailored to industrial and commercial automation applications.
