DiodesZetex Digital Transistor 100 mA NPN 50 V 3-Pin SOT-323 DDTC123YUA-7-F

Free Delivery in India | Lowest Global Shipping Charges

DiodesZetex Digital Transistor 100 mA NPN 50 V 3-Pin SOT-323 DDTC123YUA-7-F

Name: DiodesZetex Digital Transistor 100 mA NPN 50 V 3-Pin SOT-323 DDTC123YUA-7-F
Brand: DiodesZetex
SKU: 378139
Price: 0.05 USD
Availability: InStock



Category Digital Transistor Brand DiodesZetex Condition New

Specifications

Country of Origin	India
Brand	DiodesZetex
Height	1.1mm
Length	2.2mm
Model	DDTC123YUA-7-F
Width	2.2mm
Mount Type	Surface
Series	DDTC
Maximum Operating Temperature	150°C
Package Type	SOT-323
Minimum Operating Temperature	-55°C
Pin Count	3
Maximum Collector Emitter Voltage Vceo	50V
Minimum DC Current Gain hFE	68
Transistor Polarity	NPN
Maximum Emitter Base Voltage VEBO	12V
Automotive Standard	AEC-Q101
Maximum Power Dissipation Pd	200mW
Maximum DC Collector Current Idc	100mA
Transistor Configuration	Single

Key Features

Surface-mount package SOT-323 supporting automated PCB assembly.
Maximum DC collector current rating of 100 mA ensures reliable switching.
NPN transistor polarity suitable for various digital electronic circuits.
Maximum collector emitter voltage of 50 V suitable for medium voltage operation.
Maximum power dissipation of 200 mW supports low power dissipation scenarios.
Minimum DC current gain (hFE) of 68 ensures adequate amplification.
Operating temperature range from -55°C to 150°C allows versatile environmental usage.
Compact physical dimensions of 2.2 mm length, 2.2 mm width, and 1.1 mm height.

Product Description

DiodesZetex DDTC123YUA-7-F is a high-quality digital transistor designed for applications needing efficient digital switching with integrated resistor networks. This NPN transistor offers a maximum DC collector current of 100 mA and a maximum collector emitter voltage of 50 V, making it well-suited for digital switching and amplification in electronic circuits.

Packaged in a small 3-pin SOT-323 surface mount package, it supports space-saving PCB designs and automated assembly. With a maximum power dissipation of 200 mW and a DC current gain minimum of 68, it ensures effective operation within power limits and sufficient gain for digital signal processing applications.

The transistor operates reliably across a broad temperature range from -55°C to 150°C, enhancing its applicability in industrial, automotive, and commercial electronics environments. Its integrated resistor(s) allow direct connection to microcontroller or logic circuits without additional resistors, simplifying circuit design.

The device complies with the stringent Automotive Standard AEC-Q101, indicating its suitability for automotive electronics requiring high reliability under demanding conditions. Its compact physical footprint with dimensions 2.2 mm by 2.2 mm by 1.1 mm facilitates use in compact circuit boards.

Surface mount device suitable for automated PCB production. High maximum DC collector current rating of 100 mA for demanding digital loads. Integrated resistors for direct digital input drive simplifies circuit design. Wide operating temperature range for harsh environment applications.

Packaged in compact SOT-323 for space-efficient PCB layouts. Meets AEC-Q101 ensuring compliance with automotive reliability standards. Maintains low power dissipation enhancing longevity of the device. Supports single transistor configuration for versatile digital applications.

Ideal for industrial, automotive, and commercial digital electronics.

This Digital Transistor is an essential component for designers focused on compact, reliable digital switching solutions in embedded and automotive systems. Explore more semiconductor components and transistor options in our Electronics & Electricals category.
