Nexperia General Purpose NPN Transistor 100 mA, 65 V, Surface Mount SOT-457 BC846DS
Specifications
| Country of Origin | Malaysia |
|---|---|
| Brand | Nexperia |
| Height | 1.1mm |
| Length | 3.1mm |
| Model | BC846DS |
| Width | 3mm |
| Mount Type | Surface |
| Series | BC846DS |
| Maximum Operating Temperature | 150°C |
| Package Type | SOT-457 |
| Minimum Operating Temperature | -55°C |
| Pin Count | 6 |
| Maximum Collector Emitter Voltage Vceo | 65V |
| Minimum DC Current Gain hFE | 200 |
| Transistor Polarity | NPN |
| Maximum Emitter Base Voltage VEBO | 6V |
| Maximum Collector Base Voltage VCBO | 80V |
| Automotive Standard | AEC-Q101 |
| Maximum Power Dissipation Pd | 380mW |
| Maximum DC Collector Current Idc | 100mA |
| Transistor Configuration | Isolated |
| Maximum Transition Frequency ft | 100MHz |
| onsemi BC846BDW1T1G Transistor, 100 mA NPN, 65 V, 6-Pin SOT-363Brand | onsemi |
Key Features
- Maximum DC collector current of 100 mA ensures efficient switching capabilities.
- Collector-emitter voltage rating of 65 V allows operation in medium voltage circuits.
- Surface mount SOT-457 package with 6 pins for compact PCB mounting.
- High DC current gain (minimum hFE of 200) for amplification purposes.
- Stable operation over wide temperature range from -55°C to 150°C.
- Maximum power dissipation of 380 mW supports moderate power applications.
- Transition frequency up to 100 MHz suitable for high-frequency circuits.
- Complies with AEC-Q101 automotive standard ensuring reliability.
Product Description
Nexperia BC846DS is a general purpose NPN bipolar transistor designed for switching and amplification, featuring a maximum DC collector current of 100 mA and a maximum collector-emitter voltage of 65 V. Packaged in a compact 6-pin SOT-457 surface mount format, this transistor is suitable for dense PCB layouts and surface mount technology applications.
This device offers a high minimum DC current gain (hFE) of 200, ensuring effective signal amplification across a broad frequency range up to 100 MHz. It supports a maximum power dissipation of 380 mW and can operate reliably within a temperature range from -55°C to 150°C, making it versatile for industrial and automotive environments.
The BC846DS transistor is isolated in configuration with transistor polarity NPN and meets the stringent AEC-Q101 automotive industry standard, confirming its suitability for automotive electronic circuits and demanding industrial use cases. The surface mount SOT-457 package facilitates easy assembly and compact design requirements.
Maximum DC collector current of 100 mA. Maximum collector-emitter voltage of 65 V. High minimum current gain (hFE) of 200. Maximum power dissipation of 380 mW. Operates from -55°C to 150°C. Transition frequency up to 100 MHz.
AEC-Q101 automotive standard compliance. 6-pin SOT-457 surface mount package. Manufactured in Malaysia.
This transistor is commonly used in industrial electronics, automotive systems, consumer electronics, signal amplification, and switching applications requiring robust performance and reliability.
Explore more components in the Bipolar Transistors category to find compatible and complementary products for your electronics design and manufacturing needs at EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum DC collector current of this transistor is 100 mA, ensuring efficient switching capabilities.
The collector-emitter voltage rating is 65 V, allowing it to operate in medium voltage circuits.
It is packaged in a compact 6-pin SOT-457 surface mount format, suitable for dense PCB layouts.
The BC846DS operates reliably within a temperature range from -55°C to 150°C.
The minimum DC current gain (hFE) is 200, which supports effective signal amplification.
The maximum power dissipation is 380 mW, making it suitable for moderate power applications.
It has a transition frequency of up to 100 MHz, suitable for high-frequency circuits.
Yes, it complies with the AEC-Q101 automotive standard, ensuring reliability in automotive applications.
The dimensions are 3.1 mm in length, 3 mm in width, and 1.1 mm in height.
This transistor is commonly used in industrial electronics, automotive systems, consumer electronics, and signal amplification.
The maximum emitter-base voltage (VEBO) is 6 V.
The maximum collector-base voltage (VCBO) is 80 V.
