Nexperia Dual NPN and PNP Transistor 100 mA, 45 V, 6-Pin SOT-363 PMP5201Y,115

Name: Nexperia Dual NPN and PNP Transistor 100 mA, 45 V, 6-Pin SOT-363 PMP5201Y,115
Brand: Nexperia
SKU: 376642
Price: 0.28 USD
Availability: InStock



Category Bipolar Transistors Brand Nexperia Condition New

Specifications

Country of Origin	Malaysia
Brand	Nexperia
Height	1.1mm
Length	2.2mm
Model	PMP5201Y,115
Width	2.2mm
Mount Type	Surface
Series	PMP5201Y
Maximum Operating Temperature	150°C
Package Type	SOT-363
Minimum Operating Temperature	-65°C
Standards/Approvals	RoHS
Pin Count	6
Maximum Collector Emitter Voltage Vceo	45V
Minimum DC Current Gain hFE	200
Transistor Polarity	NPN + PNP
Maximum Emitter Base Voltage VEBO	-5V
Maximum Collector Base Voltage VCBO	-50V
Maximum Power Dissipation Pd	300mW
Maximum DC Collector Current Idc	100mA
Transistor Configuration	Isolated
Maximum Transition Frequency ft	100MHz

Key Features

Surface mount device suitable for compact circuit designs.
Isolated transistor configuration minimizing interference.
Maximum power dissipation of 300 milliwatts for reliable operation.
Wide operating temperature range from -65°C to 150°C.
High minimum DC current gain of 200 for efficient amplification.
Maximum transition frequency of 100 MHz suitable for high-speed switching.
Complies with RoHS environmental standards.
Manufactured in Malaysia ensuring quality and consistency.

Product Description

Nexperia PMP5201Y,115 dual NPN and PNP transistor is designed for electronic applications requiring moderate current and voltage handling capabilities. It features a maximum DC collector current of 100 mA and can withstand collector emitter voltages up to 45 V. Its isolated configuration and 6-pin SOT-363 surface mount package make it suitable for compact and efficient PCB designs.

This transistor maintains a minimum DC current gain (hFE) of 200, which enables effective signal amplification in semiconductor circuits. The maximum power dissipation rating of 300 milliwatts ensures the device operates reliably under typical industrial conditions. It supports a wide temperature range from -65°C to 150°C, making it robust in various thermal environments.

The device offers a maximum transition frequency of 100 MHz, allowing for fast switching applications in telecommunications and signal processing. Its small footprint, with dimensions of 2.2 × 2.2 × 1.1 mm, fits well in modern electronic assemblies where space is critical.

Designed according to RoHS compliance, the PMP5201Y,115 transistor is environmentally friendly. Manufactured in Malaysia, it guarantees consistent quality and performance. The dual NPN/PNP configuration enables versatile use in complementary transistor circuits for amplification, switching, and signal modulation in industrial, electronics manufacturing, automation, and consumer electronics applications.

Surface mount 6-pin SOT-363 package for easy PCB assembly. Dual transistor configuration supporting NPN and PNP types isolated from each other. Rated for continuous operation across extensive temperature ranges. Suitable for signal switching, amplification in electronic circuits, industrial control, and instrumentation.

Low power dissipation enables energy efficient designs. Compact size suitable for high-density electronic assemblies. Browse EnvMart’s broad selection of Bipolar Transistors and semiconductor devices for your industrial and electronic design needs.
