Nexperia 30 V 2 A Surface Mount Schottky Diode 3-Pin HUSON Package PMEG3020CPA,115

Nexperia PMEG3020CPA,115 is a high-performance 30 V, 2 A Schottky diode designed for surface mount applications in compact 3-pin HUSON packaging. Suitable for efficient rectification and protection in power circuits, it offers a low forward voltage drop and high switching speed.

This diode supports a maximum continuous forward current of 2 A and can withstand peak reverse voltages up to 30 V. Its ultra-small form factor with dimensions of 2.1 mm length, 2.1 mm width, and 0.65 mm height makes it ideal for space-constrained electronic designs.

Featuring a maximum forward voltage of 440 mV and low leakage current, the PMEG3020CPA,115 reduces power losses, enhancing energy efficiency in industrial, automotive, and consumer electronics applications.

The diode operates reliably over an extended temperature range from -55°C to 150°C, ensuring durability in harsh environments. It complies with AEC-Q101 automotive standards, making it suitable for automotive electronics and demanding industrial use.

Key features include a peak non-repetitive forward surge current of 9 A and a fast peak reverse recovery time of 50 ns, supporting rapid switching cycles in power supply and switching applications.

Designed with Schottky barrier technology for ultra-low forward voltage drop. Supports continuous forward current up to 2 A. Peak reverse repetitive voltage rating of 30 V ensures reliable blocking capabilities. Compact 3-pin HUSON surface mount package with dimensions 2.1mm x 2.1mm x 0.65mm.

Optimized for low capacitance and negligible power switching losses. Operates efficiently between -55°C and +150°C temperature range. Peak non-repetitive forward surge current of 9 A for transient conditions. Fast peak reverse recovery time of 50 ns enhances switching performance.

Meets AEC-Q101 automotive standard for high reliability.

This diode is extensively used in industrial electronics, automotive power management, consumer electronics, and other applications requiring efficient rectification and surge protection. It facilitates the design of compact and reliable electronic devices.
