onsemi Bus Transceiver 16-Bit Non-Inverting LVCMOS 20-Pin SOIC MC74LCX245DWG

onsemi MC74LCX245DWG is a high-performance 16-bit non-inverting bus transceiver designed with LVCMOS output levels. It features a 20-pin SOIC surface mount package optimized for compact PCB layouts. The device operates with a supply voltage range from 2.0V to 3.6V and supports 5V tolerant inputs and outputs, making it compatible with a wide variety of digital logic circuits. Its maximum propagation delay of 5ns allows fast data communication across 16 individual channels, offering efficient bus transceiver operation in multiple industrial and automotive applications.

This bus transceiver supports 3-state outputs for flexible bus control, which is essential in systems requiring shared bus access. It is designed to operate over a wide temperature range between -55°C and 125°C, ensuring reliable performance in extreme environmental conditions. The product adheres to the automotive standard AEC-Q100, demonstrating suitability for automotive-grade electronics.

The MC74LCX245DWG supports TTL-level inputs and outputs, facilitating interfacing with traditional logic families. The device provides a maximum high-level output current of -24mA and a maximum low-level output current of 24mA, meeting typical output drive requirements. Its compact dimensions - 12.95mm in length and 2.4mm in height - make it appropriate for space-sensitive applications.

Typical use cases include industrial control systems, automotive electronics, embedded applications, and any digital logic bus communication requirement where high-speed signal integrity and robust operating conditions are necessary.

Operates over voltage range 2.0V to 3.6V with 5V tolerant I/O. High-speed propagation delay of 5ns maximizes throughput. 16 channel capability with 3-state output control. Surface mount 20-pin SOIC package for compact installation.

Wide operating temperature from -55°C to 125°C suitable for harsh environments. Meets automotive standard AEC-Q100 for enhanced reliability. Supports TTL input level compatibility. Maximum output currents ±24mA for strong drive capability.
