onsemi 16-Bit Non-Inverting LVCMOS Bus Transceiver Surface Mount SOIC 20-Pin MC74LCX245DWG

onsemi MC74LCX245DWG is a 16-bit non-inverting bus transceiver designed for high-speed CMOS logic applications. It operates with a supply voltage range of 2.0V to 3.6V and is tolerant up to 5V on inputs and outputs, making it ideal for mixed voltage systems. The device comes in a surface mount 20-pin SOIC package that supports surface mounting for compact PCB layouts.

The transceiver features 16 bidirectional non-inverting channels that enable efficient data transfer between buses or within digital systems. Its TTL input levels and LVCMOS output levels provide compatibility with standard logic families. With a maximum propagation delay of 5ns at recommended load capacitance, it ensures fast switching performance.

The device supports three-state outputs with high-level output current rating of -24mA and low-level output current of 24mA, facilitating bus driving and isolation. Built to operate over a wide temperature range from -55°C to 125°C, it complies with the AEC-Q100 automotive standard, ensuring high quality and reliability for automotive applications.

The physical dimensions of the MC74LCX245DWG include a length of 12.95mm and a height of 2.4mm, allowing for tight integration in compact electronic designs. This bus transceiver is suitable for industrial, automotive, laboratory, and electronic consumer equipment requiring robust and fast logic interfacing.

Features 16 bidirectional non-inverting channels for efficient data transfer. Operates over a voltage range including 2.0 to 3.6V and maximum supply voltage of 5.5V. Equipped with 20-pin SOIC surface mount package for compact PCB design.

Compatible with TTL input levels and LVCMOS output standards. Wide operating temperature from -55°C to 125°C for diverse environments. Outputs include 3-state capability supporting bus isolation. Complies with automotive standard AEC-Q100 for reliability.

Maximum propagation delay time of 5ns ensuring high-speed data transfer. Compact physical size for space-saving electronic designs.

This onsemi MC74LCX245DWG bus transceiver is a reliable and efficient solution for bus data interfacing in various applications including industrial control systems, automotive electronics, communication devices, and general digital logic interfacing. Explore the Electronics & Electricals category at EnvMart for additional high-quality semiconductor products from trusted manufacturers.

Explore more products in our Bus Transceivers category.
