TDK SIMID 1812 Shielded Wirewound Surface Mount Inductor with Ferrite Core 22μH ±10% 450mA DC Current B82432T1223K000

Free Delivery in India | Lowest Global Shipping Charges

TDK SIMID 1812 Shielded Wirewound Surface Mount Inductor with Ferrite Core 22μH ±10% 450mA DC Current B82432T1223K000



Category Surface Mount Inductor Brand TDK Condition New

Specifications

Country of Origin	Hungary
Brand	TDK
Height	3.2mm
Length	4.5mm
Model	B82432T1223K000
Depth	3.2mm
Packaging	Tape & Reel
Series	SIMID
Maximum Operating Temperature	150°C
Minimum Operating Temperature	-55°C
Core Material	Ferrite
Inductance	22μH
Standards/Approvals	RoHS
Package/Case	1812
Maximum DC Current	450mA
Pin Count	2
Maximum DC Resistance	700mΩ
Inductance Tolerance	±10 %
Termination Style	Solder
Maximum Self Resonant Frequency	15MHz
Minimum Quality Factor	10
Inductor Construction	Wirewound
Automotive Standard	AEC-Q200

Key Features

This 1812 package size inductor has a ferrite core for enhanced magnetic performance.
The component includes effective shielding to reduce electromagnetic interference.
Rated for operating temperatures from -55°C up to 150°C, suitable for automotive applications.
Wirewound construction ensures precision inductance and durability.
Inductor supports a maximum DC resistance of 700mΩ and self-resonant frequency up to 15MHz.
Termination style is soldered, compatible with surface mount technology (SMT) assembly.
Complies with RoHS standards and meets automotive AEC-Q200 certification.
Minimum quality factor of 10 supports efficient signal filtering and power management.

Product Description

TDK B82432T1223K000 SIMID series wirewound surface mount inductor is designed with a ferrite core and features shielding to minimize electromagnetic interference, ideal for precise electronic applications.

This 1812 Surface Mount Inductor provides an inductance of 22μH with a tolerance of ±10% and supports a maximum DC current of 450mA, making it suitable for filtering supply voltages, coupling, and decoupling circuits.

Its wirewound construction ensures stable inductance across a broad temperature range from -55°C to 150°C, complying with stringent automotive AEC-Q200 standards and RoHS directives.

The component exhibits a maximum DC resistance of 700mΩ and has a maximum self-resonant frequency of 15MHz, delivering reliable performance in telecommunication, automotive electronics, and industrial electronics.

Packaged in tape and reel format, this inductor is compatible with automated PCB assembly processes, and the solder termination style facilitates secure mounting. Typical industrial applications include DC/DC converters, single-wire bus systems in automotive electronics, and various telecommunications equipment requiring stable inductance.

Manufactured in Hungary, the product embodies TDK’s quality and durability for demanding industrial and commercial electronic uses. This 1812 package size inductor offers high current handling capability suitable for power management circuits.

Shielding enhances the electromagnetic compatibility essential in sensitive electronic assemblies. Compliant with automotive and industrial standards for use in harsh environments. Perfect for industrial, telecommunications, automotive electronics, and power supply circuit applications.
