DiodesZetex 4-Channel Non-Inverting 3 State Buffer, 14-Pin TSSOP, Logic IC 74HCT125T14-13

DiodesZetex 74HCT125T14-13 is a high-speed, 4-channel non-inverting 3 state buffer logic IC housed in a 14-Pin TSSOP package designed for surface mounting. This buffer IC operates within a supply voltage range of 4.5V to 5.5V and is ideal for applications requiring buffered signals with tri-state output functionality, improving signal integrity and load driving capabilities.

Designed using CMOS technology, it combines low power consumption with high performance, consuming only 40μA supply current. The buffer supports TTL input types with a non-inverting logic function and features a maximum propagation delay of 38ns, ensuring fast signal processing for logic circuits.

This device is suitable for use in various industrial electronics and semiconductor applications requiring reliable buffering, such as signal isolation and line driving. It operates over an extended temperature range from -40°C to 125°C, making it suitable for demanding environments.

The compact 14-Pin TSSOP package has dimensions of 1.05mm in height and 5.1mm in length, facilitating space-saving PCB designs. The 74HCT125T14-13 also features ESD protection exceeding industry standards, including 200V Machine Model, 2000V Human Body Model, and over 1000V Charged Device Model, enhancing device robustness.

Typical applications include buffering signals in communication interfaces, microcontroller systems, and logic level translation. The product is manufactured in China and provided new, in line with quality and reliability requirements.

Operates within a supply voltage range of 4.5V to 5.5V. Maximum propagation delay time of 38 nanoseconds at capacitive load. TTL input type with non-inverting polarity and 3-state output functionality. Operating temperature range from -40°C to 125°C.

Low supply current consumption of 40 microamperes. Compact 14-Pin TSSOP package with height 1.05mm and length 5.1mm. ESD protection exceeding industry standards for enhanced durability. Compatible with low power Schottky logic families for easy integration.
