Molex Sherlock Series Straight Through Hole PCB Header, 5 Contacts, 2 mm Pitch, 1 Row, Shrouded 35362-0550
Specifications
| Country of Origin | Korea |
|---|---|
| Voltage | 125V |
| Brand | Molex |
| Orientation | Straight |
| Current | 2A |
| Mount Type | Through Hole |
| Contact Material | Brass |
| Series | Sherlock |
| Termination Type | Solder |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -40°C |
| Number of Rows | 1 |
| Pitch | 2mm |
| Contact Plating | Tin |
| Number of Contacts | 5 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Shrouded |
| Connector System | Wire-to-Board |
| Tail Pin Length | 3.3mm |
Key Features
- The connector system is wire-to-board, ensuring reliable electrical connections.
- Made with brass contacts plated with tin for durability and corrosion resistance.
- Rated for a current of 2A and a voltage of up to 125V.
- Designed for through hole mounting with male contacts and solder termination type.
- Tail pin length is 3.3 mm to suit PCB mounting requirements.
- Operates reliably in a temperature range from -40°C to 105°C.
- Includes polarizing ribs and wide latch area for secure mating and audible click assembly confirmation.
- Manufactured in the Republic of Korea, offering quality assurance and compliance.
Product Description
Molex 35362-0550 is a PCB Header from the Sherlock Series designed for secure wire-to-board connections in electronic assemblies. This product features a straight orientation with 5 contacts arranged in a single row, spaced at a 2 mm pitch. It is shrouded to provide protection and ensure correct mating.
Constructed using brass contact material with tin plating, this header supports a current of 2 amps and operates at a voltage up to 125 volts. The through hole mount type includes male gender contacts with solder termination for reliable PCB integration. The tail pin length is 3.3 mm, facilitating stable and secure connections.
Operating temperature ranges from -40°C to 105°C allow use in various industrial and electronic environments. The Sherlock connector system includes design features such as polarizing ribs and a wide latch area, providing secure mating retention and producing an audible click on assembly to confirm proper connection.
This connector series is suitable for applications in industrial controls, power connectors, electronic devices, manufacturing assembly, and PCB mounting scenarios. Manufactured in the Republic of Korea, it upholds quality manufacturing standards.
The connector system is wire-to-board, ensuring reliable and secure connections. Shrouded design aids protection and prevents misalignment. Brass contacts plated with tin deliver corrosion resistance and electrical conductivity.
Current rating of 2A and voltage rating of 125V suitable for moderate power applications. Single row, 5 contacts with 2 mm pitch for compact PCB layouts. Through hole mount style for robust mechanical stability. Operating temperature from -40°C to 105°C supports varied industrial environments.
Choose the Molex Sherlock Series PCB Headers for dependable, precise connector solutions in electronic and industrial manufacturing projects. Explore more components in the PCB Headers category at EnvMart for comprehensive connector solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This PCB header has a current rating of 2A and a voltage rating of up to 125V, making it suitable for moderate power applications.
It features a 2 mm pitch and has 5 contacts arranged in a single row.
The tail pin length is 3.3 mm, designed to facilitate stable and secure PCB mounting.
This model uses solder termination for reliable integration with PCBs.
It operates reliably within a temperature range of -40°C to 105°C, suitable for various industrial environments.
The contacts are made of brass and are plated with tin for corrosion resistance and electrical conductivity.
This header is shrouded, which aids in protection and prevents misalignment during mating.
It supports through hole mounting, providing robust mechanical stability.
It includes polarizing ribs and a wide latch area, ensuring secure mating retention and an audible click upon assembly.
This connector is suitable for applications in industrial controls, power connectors, electronic devices, and manufacturing assembly.
This PCB header is manufactured in the Republic of Korea, ensuring quality assurance and compliance.
The orientation of this model is straight, designed for secure wire-to-board connections.
