Wurth Elektronik Wirewound Surface Mount Inductor Composite Iron Powder Core 22 μH Moulded 600mA 3015 WE-MAPI 74438335220

Free Delivery in India | Lowest Global Shipping Charges

Wurth Elektronik Wirewound Surface Mount Inductor Composite Iron Powder Core 22 μH Moulded 600mA 3015 WE-MAPI 74438335220

Name: Wurth Elektronik Wirewound Surface Mount Inductor Composite Iron Powder Core 22 μH Moulded 600mA 3015 WE-MAPI 74438335220
Brand: Wurth Elektronik
SKU: 371501
Price: 1.71 USD
Availability: InStock



Category Surface Mount Inductor Brand Wurth Elektronik Condition New

Specifications

Country of Origin	Korea
Brand	Wurth Elektronik
Height	1.5mm
Length	3mm
Depth	3mm
Packaging	Tape & Reel
Series	WE-MAPI
Maximum Operating Temperature	125°C
Minimum Operating Temperature	-40°C
Core Material	Composite Iron Powder
Inductance	22μH
Standards/Approvals	IPC/JEDEC J-STD-020D
Package/Case	3015
Maximum DC Current	600mA
Maximum DC Resistance	1.04Ω
Inductance Tolerance	±20 %
Termination Style	Surface Mount
Maximum Self Resonant Frequency	12MHz
Inductor Construction	Moulded
Automotive Standard	AEC-Q200

Key Features

The inductor features a composite iron powder core for durability and performance.
It is moulded with an inductance tolerance of ±20 % ensuring precise electrical characteristics.
The product operates reliably within a temperature range of -40°C to 125°C.
Designed for surface mount applications with a length and depth of 3mm and height of 1.5mm.
Maximum DC resistance is 1.04Ω, supporting various electronic component uses.
Complies with automotive standard AEC-Q200 and IPC/JEDEC J-STD-020D approvals.
Ideal for DC/DC converters, portable power supplies, and wireless communication devices.

Product Description

Wurth Elektronik 74438335220 wirewound surface mount inductor from the WE-MAPI series features a composite iron powder core and a moulded construction offering 22 μH inductance with ±20% tolerance. This 3015 package SMD inductor is designed to handle maximum DC currents of 600mA and operates effectively across a wide temperature range from -40°C to 125°C, making it suitable for demanding industrial and automotive applications.

The inductor measures 3mm in length and depth with a height of 1.5mm, optimized for compact SMT PCBs. Its maximum DC resistance of 1.04Ω ensures low power losses, while the maximum self-resonant frequency is 12MHz. Certified to automotive standard AEC-Q200 and IPC/JEDEC J-STD-020D, this component is reliable for high transient current spikes and high current power supplies.

The WE-MAPI series inductors provide low acoustic noise and minimal leakage flux noise, ideal for use in DC/DC converters for field-programmable gate arrays (FPGA), point of load (POL) converters, and portable devices such as PDAs, digital cameras, smartphones, and tablets. These inductors suit industrial, laboratory, telecom, automotive electronics, and consumer electronics use cases.

The composite iron powder core construction enhances magnetic shielding and power handling. Compact 3015 surface mount design simplifies PCB assembly. Wide operational temperature range supports automotive and industrial environments.

Application versatility includes power supplies, wireless devices, and smart electronics. Compliance with industry standards ensures quality and durability.

This product is manufactured in Korea, Republic Of. Wurth Elektronik’s WE-MAPI inductors provide industrial-grade performance in a small form factor. Explore more Surface Mount Inductors and related electronic components in the EnvMart catalog for your design and production needs.
