Wurth Elektronik WE-MAPI 3015 Wirewound Surface Mount Inductor 3.3 μH Composite Iron Powder Core 1.7A 131mΩ 35MHz 74438335033
Specifications
| Country of Origin | Korea |
|---|---|
| Brand | Wurth Elektronik |
| Height | 1.5mm |
| Length | 3mm |
| Depth | 3mm |
| Packaging | Tape & Reel |
| Series | WE-MAPI |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -40°C |
| Core Material | Composite Iron Powder |
| Inductance | 3.3μH |
| Standards/Approvals | IPC/JEDEC J-STD-020D |
| Package/Case | 3015 |
| Maximum DC Current | 1.7A |
| Maximum DC Resistance | 131mΩ |
| Inductance Tolerance | ±20 % |
| Termination Style | Surface Mount |
| Maximum Self Resonant Frequency | 35MHz |
| Inductor Construction | Moulded |
| Automotive Standard | AEC-Q200 |
Key Features
- Inductor has a moulded construction designed for high rated currents.
- Features low acoustic noise and low leakage flux noise.
- Operating temperature range from -40°C to 125°C.
- Package type is 3015 with Tape & Reel packaging for efficient mass production.
- Complies with IPC/JEDEC J-STD-020D and automotive AEC-Q200 standards.
- Maximum DC resistance is 131mΩ contributing to efficient power handling.
- Maximum self-resonant frequency of 35MHz supports high-frequency applications.
- Compact dimensions with length 3mm, height 1.5mm, and depth 3mm support space-constrained designs.
Product Description
Wurth Elektronik 74438335033 WE-MAPI 3015 Wirewound Surface Mount Inductor features a composite iron powder core and a moulded construction, ideal for high current applications up to 1.7A with a precise inductance of 3.3 μH and ±20% tolerance. Designed for use in electrical and electronics industries, this inductor operates within a temperature range of -40°C to 125°C and complies with the automotive standard AEC-Q200, ensuring reliable performance in harsh environments.
The inductor has a compact 3015 package size with tape and reel packaging that facilitates automated pick and place assembly, improving production efficiency. Its low acoustic and leakage flux noise characteristics make it suitable for portable power devices like PDAs, digital cameras, smartphones, tablets, and wireless communications equipment.
The maximum DC resistance of 131mΩ and maximum self-resonant frequency of 35MHz allow efficient power handling and filtering in DC/DC converters and POL-converter circuits, crucial for smart-phones, mainboards, and graphic cards. Its surface mount termination style and moulded magnetic iron alloy construction enhance robustness and reduce EMI.
High rated current handling of 1.7A with robust magnetic shielding. Automotive-grade reliability with AEC-Q200 compliance. Compact 3x1.5x3 mm dimensions suitable for space-constrained layouts. Low noise operation for sensitive portable electronic devices.
Packaging in tape and reel format supports industrial manufacturing. Wide operating temperature range from -40°C to 125°C for various climates. Composite iron powder core enhances magnetic efficiency and stability. Inductance tolerance within ±20% ensures consistent electrical performance.
Conforms to IPC/JEDEC J-STD-020D for solderability and quality standards.
This Wurth Elektronik WE-MAPI series inductor is well-suited for industrial, commercial, and consumer electronics manufacturing environments where reliability and performance are critical. It is widely used in power supply design, signal conditioning, energy storage, and electromagnetic interference suppression in modern electronics.
Explore more high-quality inductors and electronic components with EnvMart to optimize your designs and production workflows.
