Samtec BCS Series Right Angle Through Hole PCB Socket, 20-Contact, 1 Row, 2.54 mm Pitch, 5.9A, 450V BCS-120-L-S-HE
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 450V |
| Brand | Samtec |
| Orientation | Right Angle |
| Current | 5.9A |
| Model | BCS-120-L-S-HE |
| Mount Type | Through Hole |
| Housing Material | Liquid Crystal Polymer |
| Contact Material | Bronze |
| Series | BCS |
| Termination Type | Through Hole |
| Maximum Operating Temperature | 125°C |
| Sub Type | Board-to-Board |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 1 |
| Pitch | 2.54mm |
| Standards/Approvals | CHINA RoHS, EU REACH, EU RoHS |
| Contact Plating | Gold |
| Number of Contacts | 20 |
| Connector System | Board-to-Board |
| Row Pitch | 0.1in |
Key Features
- Constructed with a black liquid crystal polymer housing for durability.
- Contacts made of phosphor bronze with 0.25μm gold plating for corrosion resistance.
- Designed for through hole mounting with right angle orientation.
- Operational temperature range spans from -55°C to 125°C.
- Compatible with several Samtec header and stacker series connectors.
- Standard 2.54 mm box connector socket strip ensuring compatibility with board-to-board connections.
- Rated for industrial electronics, suitable for power and control circuitry applications.
- Compact single row design eases PCB layout in confined spaces.
Product Description
Samtec BCS-120-L-S-HE is a right angle, through hole PCB socket designed for board-to-board connections featuring 20 contacts arranged in a single row with a 2.54 mm pitch.
The socket housing is molded from black liquid crystal polymer, providing excellent mechanical strength and thermal stability within an operating temperature range of -55°C to 125°C. The contacts are crafted from phosphor bronze and have a 0.25μm gold plating over contact areas ensuring high conductivity and corrosion resistance, while the tails have a matte tin finish to aid solderability.
This connector is rated for a maximum current of 5.9A and voltage of 450V, supporting demanding industrial and electronic applications such as power distribution, signal routing, and control systems.
Its through hole mount type with right angle orientation facilitates compact PCB designs, especially suitable for boards requiring connections perpendicular to the motherboard. The BCS series connectors are compatible with multiple mating headers including the TSW, TSM, DW, and EW series from Samtec, facilitating versatile system integration.
Black liquid crystal polymer housing offers robust mechanical performance. Phosphor bronze contacts with gold plating improve electrical reliability. Designed for through hole mounting with right angle orientation. High current (5.9A) and voltage (450V) ratings suit industrial use.
Wide operating temperature range from -55°C to 125°C. Single row with 20 contacts at 2.54 mm pitch for standard compatibility. Complies with CHINA RoHS, EU REACH, and EU RoHS environmental standards. Ideal for board-to-board connection applications in electronics manufacturing.
Part of the trusted and tested Samtec BCS connector series. Widely used in electronics manufacturing, industrial controls, power supplies, and instrumentation systems. Explore more connectors and sockets in the Power Connectors > PCB Sockets category at EnvMart to find compatible accessories and parts for your projects.
