3M 5100 Series Right Angle Through Hole PCB Socket 10-Contact 2 Row 2.54 mm Pitch 12A 1kV 5110-B7A2 PL

3M 5110-B7A2 PL is a high-quality right angle through hole PCB socket featuring 10 female contacts arranged in 2 rows with a 2.54 mm pitch. This socket belongs to the 5100 series, known for its polarized design using a center bump, making it ideal for PCB boardstacking applications such as mother/daughter board assemblies. Its right angle orientation facilitates space-saving vertical mounting configurations.

The housing is made of glass filled polyester, providing excellent mechanical strength and electrical insulation. Copper contact material plated with nickel ensures dependable electrical performance and corrosion resistance. This 12A, 1kV rated device operates reliably across a temperature range from -55°C to 105°C, suitable for demanding electronic environments.

Termination is by solder through hole type, ensuring strong mechanical and electrical connections on printed circuit boards. The socket is UL 94V-0 and RoHS 2011/65/EU certified, confirming compliance with safety and environmental standards.

3M 5110-B7A2 PL mates with standard low profile shrouded headers and includes an optional keying plug for added polarization and prevention of incorrect mating. These features contribute to its versatility and dependability in industrial, manufacturing, electronics assembly, and telecommunications applications.

This product is widely used in electronics manufacturing for creating reliable, space-saving PCB connections, supporting the assembly of stacked boards and multiplexed electronic modules.

Features a right angle orientation for PCB boardstacking applications. Constructed with a glass filled polyester housing for durability. Rated for 12A current and 1kV voltage operation. Supports operating temperatures from -55°C to 105°C.

Contains copper contacts plated with nickel for reliable conductivity. Compatible with standard low profile shrouded headers for board stacking. Includes center bump polarization to ensure correct mating. Ideal for use in electronic manufacturing requiring reliable PCB socket connections.

Termination type is solder through hole mounting for secure assembly. Meets UL 94V-0 and RoHS 2011/65/EU standards for safety and compliance. Explore the extensive range of 3M electronic connectors and sockets at EnvMart for advanced PCB assembly needs.
