Samtec SSM Series Vertical Surface PCB Socket, 50-Contact, 2 Row, 2.54 mm Pitch, 5.2A, 572V SSM-125-L-DV-P-TR

Free Delivery in India | Lowest Global Shipping Charges

Samtec SSM Series Vertical Surface PCB Socket, 50-Contact, 2 Row, 2.54 mm Pitch, 5.2A, 572V SSM-125-L-DV-P-TR

Name: Samtec SSM Series Vertical Surface PCB Socket, 50-Contact, 2 Row, 2.54 mm Pitch, 5.2A, 572V SSM-125-L-DV-P-TR
Brand: Samtec
SKU: 403884
Price: 9.65 USD
Availability: InStock



Category PCB Sockets Brand Samtec Condition New

Specifications

Country of Origin	India
Voltage	572V
Brand	Samtec
Orientation	Vertical
Current	5.2A
Model	SSM-125-L-DV-P-TR
Mount Type	Surface
Housing Material	Liquid Crystal Polymer
Contact Material	Phosphor Bronze
Series	SSM
Termination Type	Solder
Maximum Operating Temperature	125°C
Sub Type	PCB Socket Strip
Minimum Operating Temperature	-55°C
Number of Rows	2
Pitch	2.54mm
Contact Plating	Gold
Number of Contacts	50
Contact Gender	Female
Connector System	Board-to-Board
Row Pitch	2.5mm

Key Features

Features a dual vertical row design with 50 female contacts.
Pitch spacing of 2.54 millimeters suitable for standard PCB layouts.
Termination type is solder, ensuring secure electrical connections.
Constructed with liquid crystal polymer housing material for durability.
Operates reliably between -55°C to 125°C temperature range.
Supports voltage rating of 572 volts for robust electronic applications.
Contact material is phosphor bronze with gold plating for superior conductivity and corrosion resistance.
Designed for board-to-board connector system with vertical orientation.

Product Description

Samtec SSM-125-L-DV-P-TR is a vertical surface mount PCB socket from the SSM Series designed for high-reliability board-to-board connections. It features 50 female contacts arranged in 2 rows with a 2.54 mm pitch, suitable for precise electronic assembly in industrial and commercial electronics manufacturing.

The housing is made from liquid crystal polymer, providing thermal stability and mechanical strength during high temperature soldering processes. The phosphor bronze contacts are gold plated with a selective 0.000254 mm thickness to provide excellent electrical conductivity and resistance against corrosion.

This socket supports a current rating of 5.2 amperes and a voltage rating of 572 volts, allowing its use in demanding power and signal transmission environments. It functions reliably over a wide temperature range from -55°C to 125°C, making it suitable for a variety of industrial applications.

The termination method is solder, optimized for surface mount technology (SMT) with tape and reel packaging to facilitate automated placement on PCBs. The dual row vertical orientation ensures space-saving and robust connectivity for board-to-board interfaces.

Dual vertical row with 50 contacts provides reliable multi-point connectivity. 2.54 mm pitch matches industry-standard footprints for PCB design. Solder termination ensures strong electrical and mechanical bonds. Liquid crystal polymer housing offers durability under thermal cycling conditions.

High current and voltage ratings suitable for industrial and commercial electronic equipment. Gold plated phosphor bronze contacts guarantee excellent electrical performance. Wide operating temperature range from -55°C to 125°C caters to extreme conditions.

Vertical orientation supports compact board-to-board configurations. Packaging on tape and reel supports automated SMT assembly lines.

This Samtec SSM series PCB socket is ideal for use in electronics manufacturing, industrial automation, telecommunications, and other applications requiring reliable and compact PCB connections. Explore our comprehensive range of PCB Sockets and connectors on EnvMart to find compatible products meeting your specific design needs.
