Samtec SSA Series Straight Through Hole PCB Socket 5-Contact 1 Row 2.54 mm Pitch SSA-105-S-T
Specifications
| Country of Origin | India |
|---|---|
| Brand | Samtec |
| Orientation | Straight |
| Model | SSA-105-S-T |
| Mount Type | Through Hole |
| Housing Material | Polyester |
| Contact Material | Phosphor Bronze |
| Series | SSA |
| Termination Type | Through Hole |
| Maximum Operating Temperature | 105°C |
| Sub Type | Cost-Effective Socket Strip |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 1 |
| Pitch | 2.54mm |
| Standards/Approvals | RoHS |
| Contact Plating | Tin |
| Number of Contacts | 5 |
| Contact Gender | Female |
| Connector System | Board-to-Board |
Key Features
- Housing made of black PET polyester with UL 94V-O flammability rating.
- Contacts are female, made of phosphor bronze with matte tin plating.
- Mount type and termination are through hole for secure PCB mounting.
- Operating temperature ranges from -55°C to 105°C for versatile applications.
- Connector system designed for cost-effective socket strip usage.
- Complies with RoHS standards for environmental safety.
- Straight orientation ensures easy integration in PCB layouts.
Product Description
The Samtec SSA-105-S-T 2.54 mm pitch Straight Through Hole PCB Socket is a cost-effective socket strip with 5 female contacts arranged in a single row.
The socket housing is constructed from black PET polyester material, featuring a UL 94V-O flammability rating, enhancing safety and durability in electrical environments. The contacts are made of high-quality phosphor bronze with a matte tin plating that ensures excellent conductivity and corrosion resistance.
The device supports a rated voltage of up to 1000 VRMS with insulation resistance exceeding 5000 MW, providing high electrical integrity. It operates reliably within a temperature range from -55°C to 105°C, supporting usage in harsh conditions commonly found in industrial, laboratory, and manufacturing environments.
The through-hole termination and mount type ensure sturdy and robust PCB attachment, minimizing mechanical stress and ensuring stable connections. The straight orientation of the connector facilitates easy accommodation within diverse printed circuit board layouts.
5 contacts in a single row with 2.54 mm pitch for precise spacing. Black PET polyester housing with UL 94V-O flammability rating. Phosphor bronze female contacts with matte tin plating. Through hole mount and termination providing secure PCB installation.
Operating temperature range from -55°C to 105°C for wide applications. Rated at 1000 VRMS voltage and minimum insulation resistance of 5000 MW. RoHS compliant for environmental and safety standards adherence. Straight orientation for ease of layout design in electronics.
This PCB socket is ideal for use in electronics manufacturing, testing equipment, industrial controls, and other board-to-board interconnection requirements. Samtec's reliability and quality ensure performance in demanding operational scenarios.
Discover more high-quality PCB Sockets and connectors in the Electronics & Electricals category at EnvMart for your electronic assembly needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum operating temperature for this model is 105°C, allowing it to function effectively in high-temperature environments.
This socket features a pitch of 2.54 mm and includes 5 female contacts arranged in a single row.
The housing is made of black PET polyester, while the contacts are constructed from phosphor bronze with a matte tin plating.
This model has a rated voltage of up to 1000 VRMS, ensuring high electrical integrity for various applications.
Yes, the SSA-105-S-T complies with RoHS standards, ensuring it meets environmental safety requirements.
The SSA-105-S-T utilizes a through-hole termination type, providing secure attachment to printed circuit boards.
This model features a straight orientation, facilitating easy integration into various PCB layouts.
The insulation resistance for this model exceeds 5000 MW, contributing to its electrical reliability.
This PCB socket is suitable for electronics manufacturing, testing equipment, and industrial controls, among other board-to-board interconnection requirements.
The country of origin for this PCB socket is India.
The matte tin plating on the phosphor bronze contacts enhances conductivity and provides corrosion resistance, improving overall performance.
The minimum operating temperature for the SSA-105-S-T is -55°C, allowing it to operate in low-temperature conditions.
